Complete beginner's guide to using a breadboard
Summary
TLDRThis instructional video offers a practical guide for beginners in synthesizer circuit design. It covers the basics of breadboard usage, component identification, and schematic reading. The host demonstrates how to set up simple circuits using a breadboard, resistors, capacitors, LEDs, and integrated circuits, while highlighting the importance of safety and organization. The video progresses to more complex circuits, including an op-amp voltage inverter and a fixed frequency square wave oscillator, providing a hands-on approach to learning electronic circuit assembly.
Takeaways
- 🔌 Start with the basics: Understand the essentials of using a breadboard, components, and tools without diving deep into theoretical aspects.
- 🔋 Power source recommendation: For beginners, use two 9V batteries to avoid potential damage from a wall plug power supply in case of a short circuit.
- 🔗 Utilize jumpers: Pre-cut solid core wires or a roll of wire can simplify connections on the breadboard and keep the layout organized.
- 🔌 Jack sockets for audio: Use 3.5mm or 6.35mm jack sockets for input and output signals in synthesizer circuits, and connect them with soldering or alligator clips.
- 🔍 Troubleshooting tool: A digital multimeter is invaluable for measuring voltage, current, resistance, and frequency, aiding in circuit debugging.
- 📊 Resistors and their values: Small resistors can handle up to 0.4 watts and are chosen based on the circuit's need, with color bands or a multimeter for value identification.
- 💧 Capacitors variety: Different types like electrolytic, foil, and ceramic capacitors are used based on voltage rating and the application, with values typically printed on them.
- 💡 LED orientation: LEDs require correct orientation with the longer leg connected to the anode and the shorter to the cathode to allow current flow in the correct direction.
- ⚡ Integrated Circuits (ICs): ICs like the TL074 op-amp are used for specific functions and require understanding of pin functions through pinout diagrams.
- 🔄 Breadboard layout: Recognize the internal connections of a breadboard, including power rails and middle sections, to correctly place components for circuit functionality.
- 👂 Audio signal testing: Modify the oscillator circuit to produce an audible signal by increasing the frequency and using an audio socket with a voltage divider for safe listening.
Q & A
What is the main purpose of the video?
-The main purpose of the video is to guide beginners through the basics of using a breadboard to design synthesizer circuits, including identifying components, understanding breadboard internals, reading schematics, and setting up simple circuits.
Why is a breadboard recommended for starting out with synthesizer circuits?
-A breadboard is recommended for starting out because it allows for easy experimentation and modification of circuits without the need for soldering, making it ideal for learning and prototyping.
What are the advantages of using 9V batteries as a power source for beginners?
-Using 9V batteries is advantageous for beginners because they are safer than wall plug power supplies, as they will only get slightly warm in the event of a short circuit, reducing the risk of damaging components or causing injury.
What is the purpose of jumpers in a breadboard setup?
-Jumpers are used to connect components on the breadboard. They help to clean up and organize the layout of the circuit, making it easier to follow and modify.
Why is a digital multimeter a useful tool for building synthesizer circuits?
-A digital multimeter is useful for troubleshooting and measuring various electrical properties such as voltage, current, resistance, and frequency, which can be crucial for ensuring the circuit functions as intended.
What are the different types of capacitors mentioned in the script, and how can they be identified?
-The script mentions electrolytic capacitors, identified by their cylindrical shape and silver top; foil capacitors, which often come in a boxy format; and ceramic capacitors, which have a round, knob-like appearance. Their values are usually printed on the outside, and they differ in voltage rating and physical appearance.
How can one determine the resistance value of a resistor?
-The resistance value can be determined using a multimeter set to resistance detection mode. By holding each probe to one end of the resistor, the multimeter will display the resistance value.
What is the significance of the orientation of an LED when connecting it to a circuit?
-The orientation of an LED is significant because LEDs only allow current to pass through them in one direction. The longer leg of the LED should be connected to the positive side of the circuit, and the shorter leg to the ground.
How can one find out the pinout of an integrated circuit (IC) like the TL074?
-The pinout of an IC can be found by searching the chip's name followed by the word 'pinout' online. This will provide a diagram showing the function of each pin and the supply connectors.
What is the basic concept behind the voltage inverter circuit demonstrated in the script?
-The basic concept of the voltage inverter circuit is that it inverts the input voltage. If a negative voltage is applied to the inverting input, the output LED will light up, and if a positive voltage is applied, the LED will turn off.
How does the script suggest modifying the square wave oscillator circuit to make the signal audible?
-To make the signal audible, the script suggests replacing the 100k resistor between the inverting input and output with a 1k resistor to increase the oscillation frequency, and swapping the output LED for an output audio socket with a 10k-1k voltage divider to reduce the signal to line level.
Outlines
🛠️ Introduction to Synthesizer Circuit Design
This paragraph introduces the video's purpose, which is to guide beginners through the basics of designing synthesizer circuits using a breadboard. It emphasizes the practical aspects of breadboard usage, component handling, and schematic reading without delving into theoretical details. The presenter mentions that a list of necessary parts and tools will be provided in the description and highlights the importance of using batteries as a safer power source for beginners. Jumpers, jack sockets, and alligator clips are discussed as essential tools for connecting components, and a digital multimeter is recommended for troubleshooting.
🔌 Understanding Breadboards and Basic Components
The second paragraph delves into the specifics of breadboards, their tie points, and power rails, explaining how they are interconnected. It covers the use of resistors, capacitors, LEDs, and integrated circuits (ICs), including how to identify and use them in circuit design. The importance of not exceeding capacitor voltage ratings to prevent explosion is stressed. The paragraph also discusses how to read resistor color codes and the practicality of using a multimeter for determining resistance values.
💡 Building a Simple LED Circuit
This paragraph demonstrates the process of building a simple circuit to light up an LED. It explains the function of each component in the circuit, including the power source, resistor, and LED, and how they are connected. The importance of understanding the breadboard's internal connections is highlighted, with a detailed explanation of power rails and the middle section's tie points. The paragraph also addresses the correct orientation of the LED and how to connect it to the breadboard properly.
🔧 Constructing an Op-Amp Based Voltage Inverter
The fourth paragraph introduces a more complex circuit, an op-amp based voltage inverter, which inverts the input voltage to control an LED. It discusses the need for additional information beyond the basic schematic, such as powering the op-amp, which is found using a pinout diagram. The paragraph explains how to set up the IC on the breadboard, ensuring pin isolation, and how to connect the IC to power rails. It also details the steps to connect the op-amp's inputs and output to create the inverter circuit, including the use of jumpers and the importance of the IC's power supply.
🎛️ Creating a Fixed Frequency Square Wave Oscillator
The final paragraph describes the construction of a fixed frequency square wave oscillator, which automatically switches an LED on and off at regular intervals. It outlines the steps to modify the previous circuit by adding a resistor and capacitor to the op-amp's inputs and output. The paragraph also explains how to adjust the frequency of oscillation and convert the output to an audible signal by replacing the LED with an audio socket and using a voltage divider. It concludes with instructions on identifying the correct connections on the audio socket using a multimeter and connecting it to the breadboard to listen to the oscillator signal.
Mindmap
Keywords
💡Breadboard
💡Components
💡Schematic
💡Power Source
💡Jumpers
💡Multimeter
💡Resistor
💡Capacitor
💡LED
💡Integrated Circuit (IC)
💡Op-Amp
Highlights
Introduction to designing synthesizer circuits with a breadboard and components.
Explanation of the practical aspects of using a breadboard without delving into circuit theory.
List of common status items provided in the description for reference.
Use of a standard full-size breadboard with 830 tie points for ample working space.
Recommendation to use 9V batteries as a safe power source for beginners to prevent damage from short circuits.
Use of clips to connect batteries to the breadboard for easy setup.
Importance of jumpers in organizing and cleaning up breadboard layouts.
Options for connecting jack sockets to the breadboard with either soldering or alligator clips.
Introduction of a digital multimeter for troubleshooting and measuring various electrical properties.
Overview of main components used in synthesizer circuits, including resistors, capacitors, LEDs, and ICs.
Identification and handling of different types of capacitors and their voltage ratings.
Building a simple LED circuit as a foundational exercise in breadboarding.
Understanding the internal connections of a breadboard for proper circuit setup.
Creating a voltage inverter circuit using an op-amp to demonstrate basic signal processing.
Using a pinout diagram to understand the powering of an IC and matching it to a schematic.
Building a fixed frequency square wave oscillator to produce audible signals.
Adjusting the oscillator circuit to increase frequency and output through an audio socket.
Using a multimeter to identify connections on an audio jack for proper signal routing.
Final demonstration of a working square wave oscillator and listening to the generated signal.
Encouragement to explore the theory behind the circuits through the creator's DIY VCO series.
Invitation to support the creator on Patreon for additional benefits and community access.
Transcripts
let's say you want to start designing
your own synthesizer circuits
so you bought a breadboard and some
components but now you're having trouble
figuring out how to use them properly
then this video is for you in it i will
walk you through the absolute basics
from identifying and handling components
understanding the breadboard's internals
to reading schematics and then setting
up your first
simple circuits keep in mind that we
won't dive into the theory behind those
circuits
this video is strictly about the
practical aspects of using a breadboard
though if you're interested i'm
regularly doing circuit analysis videos
on my channel before we begin let's make
sure we have all the necessary parts and
tools you can find a list of common
status items in the description
so obviously the star of the show is
going to be your breadboard
and these come in different shapes and
sizes but i'm using a standard
full size variant with 830 tie points
and this will give us plenty of room to
play around with
next we need some sort of power source
if you're just starting out
i strongly recommend you use 9v
batteries here
two of them to be precise this is
because batteries
will only get a little warm if you
accidentally create a short circuit
whereas with a wall plug power supply
you might actually see things go up in
smoke
to connect the batteries with our
breadboard we'll also need
two of these simple clips here speaking
of connecting things
a box of different size jumpers can make
your life a lot easier
these are basically just pre-cut solid
core wires
so all they do is connect components on
the breadboard
but often that can really help clean up
and organize your layouts
you could of course also just buy a big
roll of wire
and cut jumpers from it yourself but for
me
this is way more convenient since we're
dealing with audio signals here
we'll also need a few jack sockets to
get those signals into
and out of our circuits you can use
3.5 millimeter once if you prefer but
i'm going with big
6.35 millimeter sockets now
in order to connect these with your
breadboard you've essentially got two
options if you're comfortable with a
soldering iron
you could simply solder wires to the
socket connectors
but in case you're not you can always
fall back on alligator clips like these
just attach them to the connectors and
to a small jumper
and you're good to go this next tool is
not exactly necessary
but it will save you a lot of headaches
especially while troubleshooting
a simple digital multimeter with it
you can measure all kinds of things the
voltage between two points
or the amount of current flowing or the
resistance value
or even an oscillations frequency super
useful
but okay time to talk meat and potatoes
here are some of the main components
you'll be dealing with
when building synthesizer circuits first
off
let's check our resistors these come in
different physical sizes which will
roughly indicate their power rating
a bigger resistor can handle more
electricity flowing through it
because it dissipates heat better with
our use case
we'll rarely be pushing large currents
through our resistors though
which is why i'm using these small and
handy ones that can handle just up to
0.4 watts
now you'll probably notice these collet
rings across
the resistor's surface and those tell
you the resistance value
if you can decipher them but honestly i
think that's too much of a hassle
which is why i normally just use my
multimeter to determine resistances
for that you simply have to set it to
the resistance detection mode
and hold each probe to one end of the
resistor you want to test
as you can see i've got a few 100k 10k
and 1k resistors here now these values
are not going to be super critical
so if you've got some that are in the
same ballpark
we should be good next we'll look at
capacitors
these can be a tad confusing because
there's a bunch of types that look
wildly different
this here for example is an electrolytic
capacitor
you can identify them by their cylinder
shape and silver top
foil caps on the other hand often come
in this kind of boxy format
and ceramic ones have this round
knob-ish appearance
now with capacitors you thankfully don't
need to learn any color codes
their value is usually printed right on
the outside somewhere
so here we have a one microfarad foil
capacitor
that can handle up to 63 volts and this
here
is a 100 microfarad electrolytic cap
that's rated for
50 volts that voltage rating is
important
your capacitors can actually explode if
you exceed it
but since we are only toying around with
9 volt batteries here
we are perfectly safe in that regard and
like with the resistors the capacitor
values are not that crucial
as long as you've got a few different
ones to play around with
next up leds these are probably
self-explanatory
you can get them in different sizes and
colors and some of them
can handle bigger currents than others
but apart from that
there's not much to look out for be sure
to buy more than one though
you'll probably fry a few along the way
still happens to me sometimes
finally we've got an integrated circuit
here or
ic for short ics are basically like
plugins
they serve a specific specialized
purpose and encapsulate that in a handy
little form factor
this one right here is a tl074
which has four independent op-amps on a
single chip
you can use other op-amp ics this is
just the one i have laying around
in spades okay so to get started let's
check out a very simple schematic
all this circuit supposed to do is make
an led
light up there's three components
involved
a power source a resistor and of course
an led it works like this electricity
flows from the battery's positive
terminal
through a current limiting 1k resistor
and the led
and then back to the battery's negative
terminal making that led
light up in the process now in most
schematics you won't find the circuit
laid out in a circular form like this
i just drew it this way because it's
easier to read at first
in the wild you'd probably see something
looking more like the schematic over
here
semantically these two are completely
identical
we just separated the positive and
negative terminal of our battery
this way we can lay out our circuit in a
more compact fashion
and once you look at more complex
designs you'll see how much that
simplifies things
with this we have all the information
needed to build the circuit
the battery connects to the resistor
which connects to the led
which leads back to the battery but now
the question is
how do we get it onto the breadboard for
this
we'll first need to understand how all
these tie points are connected
internally
so here's what we'd see if the
breadboard was transparent
you'll notice that there's a clear and
simple pattern
on the sides we have what's called the
power rails
these run all the way along the
breadboard's length
connecting all these tie points together
and are normally used to distribute
power to wherever we need it
that's why they have these plus and
minus labels
suggesting that we match them with our
batteries terminals
be careful though some breadboards split
these rails into two isolated sections
per side
and this is usually indicated by a gap
in the red and blue lines like this
and can give you some mysterious power
issues if you miss it
next let's look at our breadboard's
middle section
this is split in half by this big rift
giving us two separate areas to work
with
you'll see how that's useful later now
unlike with the power rails
the tie points in these sections are
connected across the breadboard in
chains of five
so they run perpendicular to those power
rails
okay so now that we know all this
setting up our circuit should be doable
first of all i'll connect a battery to
the power rails on this side
using one of our clips
now all the tie points on this rail
carry nine volts
while this rail sits at zero volts or
ground
looking at the schematic we can see that
the only thing directly connected to the
positive rail
is the resistor so i'll grab a 1k
and stick it into one of the positive
rails tie points
it doesn't matter which one i pick since
they all connect to our battery's 9v
terminal
then i plug the other end into one of
the middle sections tie points
and again i'm free to choose whichever i
like best
this one seems appealing so now this
entire five point row
connects to the positive rail through
the resistor
next up we'll need to plug in our led
there's a small caveat here while for
the resistor
the orientation does not matter setting
up an led
requires a little more care that's
because leds
only let current pass through them in
this direction
how do we tell these two connectors
apart then easy
you just have to check their length one
leg is always longer than the other
and that's the one that connects to our
resistor
so i'll just plug it into the same row
finally
the short leg needs to loop back to the
ground rail to complete our circuit
and while you could just squish it past
the resistor like this
i prefer to use a jumper to create a
cleaner looking layout
to do that i'll first connect the led's
short leg to a new row
then from here i can comfortably use a
small jumper
to link that row to the ground rail
and as if it's telling us we did
everything right
the led lights up great next
we'll tackle a slightly more complex
circuit idea
this is a crude op-amp based voltage
inverter
the basic idea is this if we apply a
negative voltage here
the output led will light up and if we
apply a positive voltage
it will turn off now in order to be able
to translate this
into a breadboard layout we need a bit
more information
information which is only implied in
this schematic
looking at the op-amp symbol it's
actually unclear how it's powered
we only see two inputs and one output
this is because the supply pins are only
implied here
the schematic assumes that you know you
have to power
your op amp sometimes people will draw
it with the supply pins
but that's the exception okay but how do
you power an op-amp ic
or any ic for that matter simple
you just google your chip's name in this
case tl074
followed by the word pin out this will
most likely prompt you
with what we call a pin out diagram
which shows you what each pin is for and
also indicates the supply connectors
if you're now wondering how to match
your real chips pins
with the diagram that's what this little
notch is for
which you'll find in the diagram as well
as on the actual component
okay so now we know that this pin should
get the positive
while this one's for the negative supply
voltage
only one slight problem there right now
we only have a positive and a neutral
or ground rail on our breadboard luckily
for us
adding a negative rail is really easy
when you're using batteries
all we have to do is get our second
battery
attach the clip then plug the positive
red cable into our ground rail while
connecting the black one
to a power rail on the opposite side
that's it
now we have an additional negative rail
right there
so next we'll set up our op-amp ic and
this is where this middle rift gets its
time to shine
because by plugging the chip in like
this we ensure that
all of its pins are isolated from each
other
if the rift wasn't there all of these
pin pairs
would be connected together which is not
what we want okay
time to supply the ic with power from
the pinout diagram
we know that this pin should connect to
the positive rail
so i'll use a small jumper to link this
row
to that positive rail same thing on the
opposite side
small jumper connects this row to the
negative rail
and with that our ic is powered and
ready to use
next we'll have to pick one of the four
op-amps on the chip
to build our circuit with it doesn't
matter which one we choose
so i'll go with this one here looking at
the schematic
we can start by tying the non-inverting
input
that's the one level plus to ground so
i'll use another jumper and connect this
row to the ground rail
then i'll set up our output led so we'll
first need to plug a 1k resistor into
this row
connecting it to the op-amp's output
from here
i'll route the signal to an unused row
where we'll have space
for the led next plug the led's long leg
into that row and the short leg into the
ground rail
almost done now we just need a way to
send a voltage
into the op-amp's inverting input that's
the one labeled minus
to keep it nice and simple i'll just use
a long jumper here
plug it into this row and we're good to
go
first let's send in a positive voltage
as expected the led goes dark but if i
use
the negative rail the led lights up
great
but to be honest a simple inverter is
not all that exciting
so let's pick things up a notch this
here is a simple
fixed frequency square wave oscillator
that will make our leds switch on and
off automatically
in regular intervals as you can see
there's a bunch more components at play
so let's divide things into smaller
easier to handle chunks
since the output led and current
limiting resistor are set up the exact
same way as with our previous circuit
we can simply carry them over no change
is required
next we'll deal with the op-amp's
non-inverting input
here we have to make two changes we need
to replace
the direct connection to ground with a
100k resistor
and then we need to connect that
non-inverting input to the op-amp's
output
through another 100k resistor so in
practice
i'll first remove the jumper that's
connecting this row and the ground rail
next i'll plug in a 100k resistor in its
place
finally connect these two rows with
another 100k resistor
now all that's left to deal with is the
op-amp's inverting input
the setup here is very similar to the
one down here
but it exchanges the resistor to ground
with a one microfarad capacitor
we have to be a bit cautious here this
symbol tells
us that we need to use a non-polarized
capacitor
because both of these lines are straight
if one of them were curved
we'd know to use a polarized one so
which type is polarized
and which one is not easy both the
foil and ceramic caps are non-polarized
while the electrolytic one
is polarized for audio applications
it's generally a good idea to favor foil
capacitors
so let's go with this one setting it up
is a bit tricky
because its legs are so close together
this means that we can't simply connect
one of them
to the inverting inputs row while
plugging the other
into the ground rail we'll have to find
another way
to give us a bit more space to operate
i'll first use a medium sized jumper to
connect this row
to another row further to the left
now if i connect this row to ground with
another jumper
we can comfortably plug in the capacitor
right here
so that this side is connected to the
inverting input
while this one links straight to ground
finally we'll have to connect
inverting input and output through yet
another 100k resistor
plug it in right here and as expected
the light is flashing
cool but while looking at a flashing
light is nice
it would be even better if we could
listen to our oscillator signal
for that we'll have to make two
adjustments first
we replace the resistor here with a 1k
this will increase the oscillations
frequency and make it audible
and then we'll swap our output led for
an output audio
socket to get the signal down to line
level
in order to not damage our headphones or
speakers
we use a 10k 1k voltage divider between
our socket and the op amps output let's
start out by
swapping the 100k between inverting
input and output
for a 1k resistor next i'll remove the
led
the 1k resistor here then gets replaced
with a 10k
and we can use that 1k to connect this
row to ground
finally we'll set up the audio socket
again looking at the schematic
we can see that one of its connectors
should be tied straight to the ground
rail
while the other needs to link up to the
voltage divider
now the question is how do we identify
them on the real-life socket
this is where our multimeter comes in
handy again
if we take a look at a standard mono
audio jack
we can see that it's split into two
sections the tip
and the sleeve now conventionally the
sleeve should be connected to ground
while the tip carries the actual signal
so if we insert the jack into our socket
we can use the multimeter to check for
continuity
which is just a fancy word for saying
that two points
are electrically connected for that i
set the mode dial to this setting which
in this case
is a two in one diode testing and
continuity testing
to switch it into the latter mode i
press the function button
now if i bring the two probes together
we can hear a loud beeping noise telling
us that there is
continuity so if i hold one probe
to the tip of the jack here i can use
the other
to check the sockets connectors
okay so this one should get the audio
signal
i'll attach a red alligator clip cable
to mark it
next hold the probe to the jack sleeve
and test the remaining two connectors
seems like this one should link to the
ground rail so i'll attach a black
alligator clip cable
now what about the third connector well
we can safely ignore it this is a
special kind of switched socket
but we're not using that feature here
all that's left to do
is attach the red and black cables to
small jumpers
which we can then plug into their
respective destinations
the black one connects to the ground
rail while the red one
goes where the led's long leg used to be
and now we can listen to the signal
either through headphones
or anything with an aux input audio
interfaces work too
and there you have it a nicely annoying
fixed frequency square wave oscillation
if you've made it this far you should
now be able to translate
most basic synth schematics into a
breadboard layout
now if you're curious about the theory
behind those schematics
i'd recommend you take a look at my diy
vco series
where i explain and analyze a fully
featured vco
also if you've enjoyed this content and
would like to see
more of it in the future consider
supporting me on patreon
you can get access to a bunch of
benefits there
one of which being a private discord
community where
patrons can ask for help and share ideas
anyways thanks for watching and until
next time
Parcourir plus de vidéos associées
DON'T BUY this HV Generator! Build this one instead....please
Off Delay Timer | how to make off delay timer | how to make delay timer | delay timer
Making Traffic Lights with Arduino Uno - Beginner Level (algorithm, coding, circuit design)
Circuit symbols (SP10a)
Alat sederhana tapi sangat berguna.PLN JANGAN SAMPAI TAU !!
2nd Order Oscillatior Circuit
5.0 / 5 (0 votes)
