t-SNE Simply Explained

Summary

This video explores the T-Distributed Stochastic Neighbor Embedding (t-SNE), a powerful method in machine learning for reducing high-dimensional data to two or three dimensions for visualization. Unlike PCA, t-SNE focuses on preserving local structures by comparing data points pair-by-pair. The video delves into the algorithm's mechanics, including the use of a Gaussian distribution in high dimensions and a heavier-tailed distribution in lower dimensions to combat the curse of dimensionality. It concludes with a comparison to PCA, highlighting t-SNE's non-linearity and computational complexity.

Takeaways

• 📚 The video introduces a method called t-Distributed Stochastic Neighbor Embedding (t-SNE), used for reducing the dimensionality of high-dimensional datasets.
• 🔍 t-SNE is distinct from Principal Component Analysis (PCA) in that it operates on a pair-by-pair basis, focusing on preserving local relationships between data points.
• 📈 The method begins by defining the probability of one data point choosing another as its neighbor based on their distance in the high-dimensional space.
• 📉 t-SNE uses a function for calculating probabilities that resembles the division of two Gaussian probability density functions, aiming to maintain local structures in the lower-dimensional representation.
• 🌐 The algorithm dynamically selects a standard deviation (σ) for each data point to fit a certain number of neighboring data points within a specified number of standard deviations.
• 🔗 t-SNE creates a similarity score (p_ij) that represents the likelihood of data points i and j being grouped together, based on their closeness in the high-dimensional space.
• 📉 The goal of t-SNE is to find a lower-dimensional representation (y1, y2, ..., yn) that preserves the similarity (p_ij) between data points as computed in the high-dimensional space.
• 🔑 The challenge of dimensionality reduction is addressed by using a Student's t-distribution with a degree of freedom of one (a Cauchy distribution) in the lower-dimensional space, which has heavier tails than a Gaussian distribution.
• 📝 The algorithm employs the KL Divergence to measure the difference between the original high-dimensional similarities (p_ij) and the new low-dimensional similarities (q_ij), aiming to minimize this difference.
• 🤖 t-SNE uses gradient descent to adjust the positions of the lower-dimensional points (y_i, y_j) to minimize the KL Divergence, thus finding an optimal representation.
• 🚀 t-SNE is more computationally complex than PCA due to its focus on individual data point relationships and is particularly effective for datasets that are not linearly separable.

Q & A

What is the full name of the method discussed in the video?

The full name of the method discussed in the video is T-Distributed Stochastic Neighbor Embedding, often abbreviated as t-SNE.

What is the primary goal of t-SNE?

The primary goal of t-SNE is to reduce the dimensionality of a high-dimensional data set to a much lower-dimensional space, typically two or three dimensions, to enable visualization of the data.

How does t-SNE differ from Principal Component Analysis (PCA) in terms of its approach to dimensionality reduction?

t-SNE operates on a pair-by-pair basis, focusing on preserving the local relationships between individual data points in the new lower-dimensional space, whereas PCA works on a global level, focusing on directions of maximum variance in the data set.

What is the significance of the probability P(J|I) in t-SNE?

P(J|I) represents the probability that, given data point I, it would choose data point J as its neighbor in the original high-dimensional space. It is a key component in defining the local relationships between data points.

How does t-SNE address the 'curse of dimensionality' when mapping high-dimensional data to a lower-dimensional space?

t-SNE addresses the curse of dimensionality by using a heavier-tailed distribution, specifically a Student's t-distribution with one degree of freedom (also known as a Cauchy distribution), to maintain higher probabilities for longer distances in the lower-dimensional space.

What role does the KL Divergence play in the t-SNE algorithm?

The KL Divergence is used as a loss function in t-SNE to measure the difference between the original high-dimensional similarities (p_ij) and the new low-dimensional similarities (q_ij). The goal is to minimize the KL Divergence to ensure that the low-dimensional representation preserves the local structures of the high-dimensional data.

How does t-SNE handle the dynamic setting of the standard deviation σ_i for each data point?

t-SNE dynamically sets the standard deviation σ_i for each data point based on the number of neighboring data points within a certain number of standard deviations of the Gaussian distribution. This allows t-SNE to adapt to different densities in the data, with lower σ_i for denser regions and higher σ_i for sparser regions.

What is the motivation behind using the Gaussian distribution to define probabilities in the high-dimensional space?

The motivation behind using the Gaussian distribution is that it naturally incorporates the distance between data points into the probability calculation, with closer points having higher probabilities of being chosen as neighbors and more distant points having lower probabilities.

How does t-SNE ensure that the local structures between data points are preserved in the lower-dimensional space?

t-SNE ensures the preservation of local structures by minimizing the KL Divergence between the original high-dimensional similarities and the new low-dimensional similarities, thus maintaining the relative closeness of data points that were close in the original space.

What computational method is used to find the low-dimensional representations (y_i) in t-SNE?

Gradient descent is used to find the low-dimensional representations (y_i) in t-SNE. The algorithm iteratively adjusts the positions of the data points in the lower-dimensional space to minimize the KL Divergence between the original and new similarity measures.

Outlines

00:00

📚 Introduction to t-SNE for Dimensionality Reduction

The video introduces a method called t-Distributed Stochastic Neighbor Embedding (t-SNE), used in machine learning and data science to reduce the dimensionality of high-dimensional datasets. Unlike Principal Component Analysis (PCA), t-SNE operates on a pair-by-pair basis, aiming to preserve the local relationships between data points in a lower-dimensional space, typically two or three dimensions, for visualization purposes. The method begins by defining the probability of one data point choosing another as its neighbor based on their distance in the high-dimensional space.

05:00

🔍 Defining Neighbor Probabilities in High-Dimensional Space

This paragraph delves into how t-SNE quantifies the likelihood of data points being neighbors based on their distances in high-dimensional space. It explains the formulation of probabilities using a Gaussian distribution, where the probability of choosing a neighbor decreases with increasing distance. The function accounts for all other data points in the dataset, ensuring that the selection of a neighbor is relative to the local context of each data point's position.

10:01

📉 Adjusting Probabilities for Dynamic Standard Deviation

The script discusses the dynamic selection of the standard deviation (σ) for the Gaussian distribution used in calculating neighbor probabilities. The choice of σ is tailored to fit a specific number of neighboring data points within a certain range of standard deviations. This dynamic adjustment accommodates varying densities of data points in different regions of the high-dimensional space.

15:01

🔗 Preserving Local Structures in Lower-Dimensional Space

The paragraph explains the goal of t-SNE to learn a lower-dimensional representation of data points while preserving the local similarity computed in the high-dimensional space. It introduces the concept of using a Gaussian distribution to measure similarities between points in the lower-dimensional space and the challenge of ensuring that these similarities match the original high-dimensional similarities.

20:02

📊 The Curse of Dimensionality and t-SNE's Solution

This section addresses the challenge of the curse of dimensionality, which arises when trying to map high-dimensional data into a lower-dimensional space. The video illustrates how the area occupied by data points at a moderate distance from a target point increases exponentially with the number of dimensions. To overcome this, t-SNE modifies the similarity definition in the lower-dimensional space by using a heavier-tailed distribution, such as the Cauchy distribution, to maintain higher probabilities for larger distances.

25:04

📈 Utilizing the Student's t-Distribution for Similarity

The video explains the rationale behind using the Student's t-distribution with one degree of freedom (equivalent to the Cauchy distribution) in the lower-dimensional space. This distribution has heavier tails, allowing t-SNE to accommodate the increased probability of selecting a neighbor over a broader range of distances, thus addressing the limitations imposed by the curse of dimensionality.

🔧 Gradient Descent Optimization for t-SNE

The final paragraph outlines the optimization process of t-SNE, which involves using gradient descent to minimize the KL Divergence between the original high-dimensional similarities (p_ij) and the new low-dimensional similarities (q_ij). The goal is to find the lower-dimensional representations (y_i, y_j) that best preserve the local structures of the high-dimensional data.

🌐 Comparing t-SNE with PCA and Conclusion

The video concludes by contrasting t-SNE with PCA, highlighting that t-SNE is more focused on preserving local structures and does not assume linearity in the data, making it suitable for non-linear datasets. In comparison, PCA is a linear method that works well with linearly correlated data. The presenter invites viewers to leave questions or comments and encourages them to like, subscribe, and watch more videos on similar topics.

Keywords

💡Dimensionality Reduction

Dimensionality reduction refers to the process of reducing the number of random variables under consideration and can also involve reducing the number of observations in a dataset. In the context of the video, dimensionality reduction is achieved through the T-Distributed Stochastic Neighbor Embedding (t-SNE) method to transform high-dimensional data into a lower-dimensional space, typically for visualization purposes.

💡t-SNE

t-SNE, short for T-Distributed Stochastic Neighbor Embedding, is a machine learning algorithm used for visualization by reducing the dimensionality of high-dimensional data sets. The video script explains t-SNE as a method that operates on a unit by unit level, preserving the local structure of the data in a lower-dimensional space, unlike PCA which works on a more global level.

💡Principal Component Analysis (PCA)

PCA is a statistical technique that transforms a set of observations of possibly correlated variables into a set of linearly uncorrelated variables called principal components. The script contrasts PCA with t-SNE, highlighting that PCA focuses on global variance while t-SNE is concerned with local structures and pairwise relationships.

💡Probability Distribution

A probability distribution is a mathematical function that provides the probabilities of each possible outcome in an experiment. In the video, the script describes how t-SNE uses a probability distribution to define the likelihood of choosing a neighbor in the high-dimensional space, which is essential for preserving local structures in the lower-dimensional space.

💡Gaussian Distribution

The Gaussian distribution, also known as the normal distribution, is a probability distribution that is used in the initial steps of t-SNE to model the probability of choosing a neighbor based on distance in the high-dimensional space. The script mentions that the probability of selecting a neighbor is proportional to the normal distribution of the distances.

💡KL Divergence

KL Divergence, or Kullback-Leibler divergence, is a measure of how one probability distribution diverges from a second, expected probability distribution. In the context of t-SNE, the script explains that KL Divergence is used to minimize the difference between the original high-dimensional similarities (pij) and the new low-dimensional similarities (qij).

💡Stochastic

Stochastic refers to a process involving randomness or probability. The script uses the term 'stochastic' in the name t-SNE to indicate that the method is based on random processes, particularly in the way it defines the probability of choosing a neighbor.

💡Embedding

In the context of the video, embedding refers to the process of mapping high-dimensional data into a lower-dimensional space. t-SNE is described as an embedding method that aims to preserve the local structure of the data while reducing its dimensionality.

💡Curse of Dimensionality

The curse of dimensionality refers to various phenomena that arise when analyzing and organizing data in high-dimensional spaces. The script discusses this concept in relation to t-SNE, explaining that as dimensionality increases, the volume of the space becomes increasingly larger, making it difficult to represent mid-level distances in a lower-dimensional space.

💡Student's T-Distribution

Student's T-Distribution, also known as the T-distribution, is a type of probability distribution used in t-SNE for the lower-dimensional space. The script explains that this distribution has heavier tails than the normal distribution, allowing for a broader range of distances to be considered similar, which is necessary to overcome the limitations posed by the curse of dimensionality.

Highlights

Introduction to T-Distributed Stochastic Neighbor Embedding (t-SNE), a method for reducing the dimensionality of high-dimensional data sets.

Comparison between t-SNE and Principal Component Analysis (PCA), highlighting t-SNE's unique approach to dimensionality reduction.

Explanation of t-SNE's operation on a unit-by-unit level, preserving the relationship between data points in a pair-by-pair basis.

The concept of probability in selecting a neighbor data point based on distance in the high-dimensional space.

The formulation of probability as a function of distance, emphasizing the likelihood of choosing closer data points as neighbors.

Inclusion of all other data points in the probability function to account for the global context within the data set.

The properties required for the probability function, including negative correlation with distance and positive correlation with relative closeness.

Introduction of the specific function recommended by t-SNE authors, resembling the division of two Gaussian probability density functions.

Validation of the function's properties to ensure it meets the criteria for neighbor selection based on distance.

The dynamic selection of standard deviation (σ) for each data point to fit a certain number of neighboring data points within a Gaussian distribution.

The definition of similarity score (p_ij) as a balance between the probabilities of data points grouping together.

The challenge of preserving local structures in the lower-dimensional space while reducing dimensionality.

The mechanics of translating high-dimensional data points to a lower-dimensional space while preserving similarity.

The issue of the curse of dimensionality and its impact on the algorithm's ability to pack mid-level data points into a lower-dimensional space.

The solution to the curse of dimensionality by using a heavier-tailed Student's T-distribution with one degree of freedom in the lower-dimensional space.

The rationale behind using a Student's T-distribution to maintain similarity over a broader range of distances in the lower-dimensional space.

The use of KL Divergence to minimize the difference between the original high-dimensional similarities (p_ij) and the new low-dimensional similarities (q_ij).

The final step of finding the low-dimensional representations (y's) using gradient descent to minimize the KL Divergence.

The contrast between t-SNE's pair-by-pair approach and PCA's global variance approach, with t-SNE being more suitable for non-linear data sets.

The computational complexity of t-SNE compared to PCA, due to its focus on individual data point relationships.

Transcripts

[Music]

hey what's up everybody today we're

going to be talking about a very cool

method in machine learning and data

science to reduce the dimensionality of

a data set who has very very high

dimensional data in a very different way

than for example principal component

analysis and at the end of the video

we'll talk about pros and cons of those

two methods

but this method is officially called the

T distributed stochastic neighbor

embedding that's a very long title I

couldn't even fit all of the words

without these little abbreviations here

so people typically call it t Snee so we

have t s and e t Snee and as we were

saying before the idea is that we come

to this method with a bunch of data

points in a pretty high dimensional

space

so we have n data points X1 X2 all the

way to xn and each of these are vectors

in a very high dimensional space you can

think of dozens or hundreds or even

thousands of dimensions for each of

these vectors

and our goal is to eventually get a set

of n vectors y1 Y2 all the way to YN who

are in a much much lower dimensional

space typically a two or three

dimensional space which lets us do

things like visualize this data which we

couldn't do before

so we're going to start by asking a

series of questions the key Insight the

key idea behind TC and what makes it

fundamentally different from PCA is that

TC is operating on a unit by unit level

so it's looking at X1 and X2 and trying

to preserve something about the

relationship between those two data

points in your original data

it's trying to preserve that

relationship in the new data which is

going to be in lower Dimensions so it's

working on a pair-by-pair basis whereas

PCA is working on a more Global level

we'll say a lot more on that later

the first question we're going to ask

here is given some data point in this

set of n data points x i

what's the probability that it would

pick some other data point x j as its

neighbor

this kind of seems like a vague question

but we can quantify we can Define that

quantity as P J given I so this notation

says given that you are the data point I

what's the probability that you would

pick the data point J as your neighbor

now there's lots of ways you could

Define this but one very natural way is

going to be making it a function of the

distance between x i and XJ again in

this High dimensional space

so we're going to say the probability

that if I'm I I would pick J as my

neighbor is going to be some function I

don't know what the function looks like

yet but it's going to be some function

of the distance between x i and x j the

smaller this distance is the more likely

I would want to pick that one as my

neighbor because it's closer to me

the further this data point x j is the

less likely I want to pick it as my

neighbor

now this formulation almost makes sense

but it ignores the fact that there's all

these other data points going on in our

data there's not just x i and XJ imagine

your x i and you're being asked who are

you going to pick as your neighbor well

I need to know information about all the

other data points are there others that

are way closer to me is XJ actually the

closest to me and everyone else is

further away

so while this attempt number one does

start getting us to the right place

we're going to need to expand what our

function is based on so we're going to

say this probability is now a function

of I've just made a shorter notation

here d i j squared is just this distance

between I and J squared and it's going

to include information about the same

distances from I to all of the other

data points in our data so all distances

ik where K is not equal to I or not

equal to J and whatever function this is

is going to need to have a couple

properties and I've noticed now I've got

these reversed so we're doing this in

real time let me fix this so this is

going to be negative and this is going

to be positive so the first property is

that the bigger the distance gets

between I and J the lower we're going to

have the probability I would pick that

as my neighbor it's going to be

negatively correlated and the other

property is for all the other data

points that I'm not considering that are

not equal to irj if the distance to them

gets bigger and bigger and bigger then

everything else held constant J becomes

more and more attractive because it's

relatively closer to me and so my

probability should go up in that

situation so what might such a function

f look like

and the authors of T Snee recommend

using this function here which is going

to seemingly come out of nowhere but

I'll try to motivate it as best I can

so they say this function pji the

probability I would pick J is my

neighbor if I am the data point I is

going to be this very ugly looking form

but if you stare at it for a little bit

and try to remember what it looks like

from your introductory statistics

courses this exactly looks like the

division of two normal probability

density functions two gaussian

probability density functions and that's

exactly where the motivating comes from

so the paper authors say that we're

going to assign these probabilities PJ

given I proportional to the density of a

normal

of a normal distribution of the distance

so the main things we should check first

are do the properties you want out of

this function based on what we just came

up with here actually hold well this

distance here so this guy here is the

distance between x i and x j squared if

this increases then because there's a

negative sign in front of it the whole

exponent here is going to decrease and

if we take e to the power of an Ever

decreasing number then the entire

numerator is going to decrease so we

exactly have the first criteria and we

can see it we also have the second

criteria met if any of the other data

points who are not equal to IR J in the

denominator if they increase then the

entire denominator is going to decrease

and therefore the entire probability is

going to increase exactly as we wanted

so while this form itself May seemingly

come out of nowhere and to be quite

honest with you we probably could have

chosen different forms this was just the

form that was chosen perhaps for

mathematical convenience in the actual

algorithm the properties we want do in

fact hold and that's all we really care

about for right now but the motivating

factor behind this was that we're going

to assume that as the distance moves

further away the probability that you

would choose data point J if you were

data point I is going to be proportional

to the normal distribution of the

distances between those two and also the

distances between you and all the other

data points that exist out there

so the next question we're going to ask

is well this was telling us about data

points I and data point J let's zoom out

a little bit and say if we were to pick

a point at random from all of our n data

points what's the probability that I and

J end up grouped together

well this could happen in two different

situations the first is that the random

point we chose is data point I

that happens with the 1 over n

probability because all the data points

have equal probability of being picked

in this situation and given we chose

data point I what's the probability that

it would choose data point J as its

neighbor well that's exactly what we

spent so much time coming up with here

and that's exactly the quantity PJ given

I

now there's one other way that we could

have inj grouped and that would be if

the data point we pick in this little

experiment here was data point J

and if we picked data point J which

happens with the one over n probability

then the probability that inj would be

grouped is now the same as the

probability that data point J would pick

data point I which is going to be just

the opposite here so given I'm data

point J what the probability I picked

data point I

and now these two things together

if we do this multiplication in this

addition we're going to Define as p i j

which is going to be some form of

similarity score

between the data points I and J because

that represents the probability that

they would end up together in a group

and this captures both it's kind of a

balance in fact it's a literal averaging

between this pji and this p i j so we

can put p j i plus p i j and we divide

that by the number of data points there

are and this gives us a score which we

can interpret as a probability of I and

J being similar to each other and this

is all going to be based on their

physical closeness to each other in this

High dimensional space

now there's a note that I kind of

glanced over here some of you might be

wondering how do I pick this Sigma I

because when you have a gaussian

distribution it's defined by a mean and

a standard deviation and I didn't really

talk about how that standard deviation

which based on the subscript I seems to

be a function of I gets set

there's a ton more details in the

original paper which I'll link in the

description below but here's the general

intuition

we're going to pick that standard

deviation dynamically for each of our

data points from 1 to n

so that it's going to fit a certain

number in general it's going to fit a

certain number of neighboring data

points in some number of standard

deviations of that gaussian distribution

and so that seems a little bit abstract

but let me make it a little bit more

concrete here now let's say you're

looking at some data point I and you're

looking at all the other data points and

what distance they have away from your

data point I so this vertical line here

is going to be a distance zero and I

didn't even need the negative side of

this plot should have really just drawn

the positive side but let's say you have

four other data points that are right

here

so you would use this red distribution

here if your rule was something like

within the first two standard deviations

of my normal distribution which would

cut off around here I want four data

points and that's exactly what we've

been able to achieve within this first

two standard deviations you have four

data points now here's a different case

you have for a different data point x

sub I that you might be looking at let's

say that its neighbors are here here

here and here

now you can't use that same red normal

distribution because if you were to then

the first two standard deviations you

only have two data points there's the

sparsity issue going on and so we allow

this Sigma sub I to be dynamic so that

we can use this black normal

distribution here because within its

first two standard deviations we do have

now those four neighboring data points

so there are a lot more details I am

oversimplifying it a little bit here but

the general idea is that if around

whatever Point you're looking at

there's a lot of very close neighbors so

it's in a very dense part of the space

then you can set Sigma sub I to be low

you don't need a really big standard

deviation for your normal distribution

if on the other hand your data point x i

is in a very sparse part of the space

where it's here but its closest

neighbors are like really far away

which is the situation we were looking

at with this black points here then you

want to set that standard deviation

appropriately to be higher so let's take

stock of where we're at so far we have p

i j which is going to give us some

measure of similarity between the data

point I and the data point J

and now we can start talking about how

do we get to that lower dimensional

space

the goal is to learn a low dimensional

representation again in tcne that

usually means a two or three dimensional

representation because people typically

want to do this so that they can

actually visualize their data on some

kind of plot

so we're going to translate our X1 X2

all the way to xn which are high

dimensional into y1 Y2 all the way to YN

which are low dimensional for example

they could be in two-dimensional space

and we want to do it in such a way that

we're going to preserve the similarity

that we just computed which are again

these p i JS between data points x i and

XJ so if the similarity between data

points X1 and X2 was like 0.1 then we

want to do our best to preserve that

similarity in the data points y1 and Y2

even though they're in a lower

dimensional space and this is probably

the most important part of the video the

intuition the goal we're trying to do

the how is really just more mechanics

but the power behind tisney is that it's

looking at pairs of data points and

seeing what similarity we gave it based

on this formulation here and saying that

you know what I know we want to put the

data in a lower dimensional space but I

don't want to sacrifice on these

similarities I want to preserve these

local structures between my data points

that were there before I want those

local structures to still be there right

now

and now we can get into the actual

mechanics how are we going to actually

do this well why don't we just try the

most straightforward thing first based

on what we've already used in this

method so far and that's going to be

just like with the X's how we measured

this similarity using this gaussian

framework why don't we just do the exact

same thing with the Y's so just like for

the X's we measure the similarities

using the gaussian just do the same

thing with the Y's measure them using

the gaussian and now you'll have some

values q i j which are the similarities

between the Y's and now all you need to

do is make sure the qijs and the pijs

are similar to each other

now that is a great first attempt and

avoids any unnecessary complications but

we should talk about a very subtle thing

that goes wrong when we do that and this

is all under the umbrella of the curse

of dimensionality which we knew was

going to come along when we're dealing

with very high dimensional data and here

is how it rears its ugly head

to demonstrate this I'm just going to

show in two and three dimensions so

we're going to treat our two-dimensional

space as our Target space for tisney and

we're going to say the three-dimensional

space is the original space the data

points are in of course your data points

are probably going to be in a way higher

dimensional space but this is just for

illustration

what I want to do here in two Dimensions

because I can draw in two dimensions for

you all not well apparently but what I'm

going to do in two Dimensions is draw an

area of two-dimensional space who has a

distance of one from the origin and

that's this little green circle here

and we're going to call this the nearby

area all these points are going to be

nearby to whatever my target data point

in the origin is

this Blue Area we're going to call the

mid distance area so it's between a

distance of one and two

and what I want to do here is a very

simple equation I want to divide the

area of the mid region which is this

outer blue ring by the area of the near

region which is this inner green circle

now we know how to do it just pi r

squared is the area of a circle and so

the area of the mid region is going to

be the area of this big circle minus the

area of the small circle which is the

numerator and the area of the nearby is

just going to be the area of the small

circle or Pi 1 squared and we get that

that ratio is equal to 3.

so what this means is that the mid size

the area of the mid region where those

data points were a middle distance away

from me is three times the area of the

data points we're allowed to be a near

distance from me now stay with me here

let's do this for one dimension up in

this case we're not dealing with areas

we're dealing with volumes and I haven't

even dared to draw it but you can

visualize a sphere of points who all

have a distance of one or less from the

origin or the unit sphere

is going to be what we're calling the

volume of the nearby region in three

dimensions very analogous to the area of

the nearby region in two dimensions and

the volume of the mid in three

dimensions is going to be the area

between a sphere who has distance two

just like we had this circle with

distance two everything between the

outside of that and the outside of the

inner sphere

so we can do a very simpler formula we

appeal to the volume of a sphere here

and we get that the ratio is equal to

seven

and now here's the punch line

in two-dimensional space we found that

the area of the mid data points was

three times the area of the near data

points but in three-dimensional space

the volume in which the mid-level data

points are allowed to occupy is a whole

seven times bigger than the volume of

the nearby data points are allowed to

occupy

and where this is all leading up to how

we can verbalize the problem here is

exactly like this

when we're going from a high dimensional

space to a low dimensional space in this

case just kind of trivializing it going

from a three-dimensional space to a

two-dimensional space we're trying to

take all these mid-level data points

where a mid distance away from whatever

Target data point we care about

and that has you can say a size of seven

and we're trying to pack that into a

mid-size area in the lower dimensional

space who has a you can say size of

three

so the problem is that we're trying to

pack all the midpoints in high

dimensional space the midpoints in a

high dimensional space into a much much

smaller space in a lower Dimension and

the problem doesn't seem so pronounced

with just two and three dimensions but

imagine that your data point has just 10

Dimensions which is not crazy by any

data science standards typically when we

use T Snee we're trying to embed like

1000 or 100 dimensional embeddings

even if your data just has 10 Dimensions

this problem becomes such that you're

trying to take a mid-size space and I'm

kind of using this word loosey-goosey

but what I'm really trying to say is the

area in that higher dimensional space

which is occupied by the data points who

are a moderate distance away from you

and with a 10-dimensional space that has

a 1023 ratio with the nearby area and as

we saw in a two-dimensional space that

has a ratio of just three

so we run into just this kind of like

I'm running out of space I can't take

all the data points who have a certain

characteristic in a high dimension and

pack them into the same characteristic

in the low Dimension there's just not

enough room in that low dimensional

space

and the way we solve for that is

actually changing up our definition of

similarity in that lower dimensional

space and we do that in a visual way so

in the high dimensional space we are

using this normal distribution where the

x-axis here is distance away from your

target data point

and the y-axis is telling you what's the

probability that I would pick that data

point as my neighbor

and as we said this drops off as a

gaussian the further the data point away

the lower that we have this probability

you pick it as your neighbor and the

trend is gaussian

now as we said let's focus on a very

specific area of this plot between

distances of one and two which is what

we were classifying as moderate

distances in the high dimensional space

now if it's a distance of one away then

the probability I would pick that as my

neighbor is around here and if it's a

distance of 2 away the probability I

would pick that as my neighbor is like

right here but as we said in the low

dimensional space we don't have enough

room and so the way we solve that is

just by changing expanding our

definition of what it means to be in a

mid-dimensional space the the area

between one and two distance is just too

restrictive I need a lot more range to

work with in order to fit all these data

points that you want me to fit and so

what we might say for example is I want

the whole range between distances 1 and

4.

and what that implies is that whatever

probability we had for picking J as our

neighbor if its distance was two we now

need to accept that same probability if

the distance is four because we're

expanding the definition of what it

means to have a mid-dimension since we

didn't have enough space in that lower

dimensional space

so what that means is that if we

continue this line which was at 2 we're

now asking for that line to be at four

and what this implies even though I

really should have drawn this more

exaggerated what this implies is that

whatever distribution we're now using to

translate distances to scores or

probabilities is going to need to have

much heavier Tails than the normal

distribution because if we try to draw

this thing now it can't fall off at the

same rate as the normal distribution it

needs to fall off at a much heavier tail

it needs to maintain a higher

probability for longer and longer and

longer

and therefore we can't use a normal

distribution at all because its tails

fall off at the same rate no matter what

standard deviation you're talking about

so we switch in our lower dimensional

space to a heavier tailed students T

distribution with a degree of Freedom

equals equals one which is actually the

same thing as a kaushi distribution

now you don't need to at all get into

the nitty-gritty of what these

distributions are and their PDFs or

anything really I just want you to focus

on the picture here

we're just picking a distribution who

has a heavier tail than the normal

distribution and the reason we're doing

that is to deal with this cursive

dimensionality issue

and the main thing you need to realize

between these two plots is that whatever

the probability was at 2 in the higher

dimensional space we're asking the

probability to remain there for longer

and longer and longer to accommodate

higher and higher and higher distances

away to have the same property

to have the same similarity as we did

for these smaller distances in the high

dimensional space

so this honestly was the part of

learning about this algorithm that took

the most time for me to wrap my head

around I was like what is going on why

are we not just using the normal

distribution the seems to have come out

of nowhere but I'm hoping that perhaps I

over explained it here and it was pretty

obvious too but I would rather over

explain than under explain because you

can always just seek the video to where

you want but hopefully this helped

motivate why we are using a student's T

distribution and the other reason I

really wanted to get that across is

because it's in the name of this whole

thing it's called the T distributed

stochastic neighbor embedding and while

we're on this page let's make sure we

understand where all these terms come

from we know exactly about the

t-distribution part now uh stochastic

because this is all based on random

processes we're dealing with

probabilities here neighbor because

we're dealing on a neighbor by neighbor

basis That's the basis on which this

algorithm works and embedding because

we're trying to get our high dimensional

embeddings which we are at here to a

much lower dimensional space which is

where we we are going right now

so we're almost done here

now that we've accepted that we're going

to use a one degree of Freedom students

D distribution more simply known as a

kaushi distribution we can go ahead and

just do the same form as we had a couple

of pages ago so this form while it looks

complicated is really just mirroring the

pij form we had before

so now we're saying qij which is going

to be the similarity or the probability

between the if and jth of your new your

lower dimensional embeddings y i y j is

going to be defined in this way and the

reason the form looks like this is

because that's the probability density

function of the kaushi distribution or

the student's T distribution with one

degree of freedom and the denominator

we're of course normalizing that by

dividing by all the other data points

that exist in there

the final step is that well now we have

our pijs which tell us how similar the

higher dimensional embeddings were for I

and J we have qij which tells us how

similar our lower dimensional embeddings

were for data points I and J we want

them to be close to each other because

that's the whole point of statistney is

that we want to make sure that if pij

was a certain number qij should be as

close to that as possible

and we can show that pij and qij are

both probability distributions and what

does it mean for us to enforce the two

probability distributions are close to

each other we can use our good friend

the KL Divergence

and we have a whole video on KL

Divergence I'll post that below but in a

nutshell it's just telling us what's the

level of difference between two

probability distributions we want the KL

Divergence between the P which is the

original High dimensional similarities

and Q which is the new low dimensional

similarities to be very small ideally

you want to be zero but we can't have

everything we want because we're going

we're losing information by going to

load Dimensions so we want it to be as

low as possible

and finally the way we actually find

these y's is via gradient descent so you

can think of this as our loss function

and we could just take the derivative of

this loss function with respect to all

these y I's and yjs and move the Y I's

and Y J's until the KL Divergence is as

low as possible

and so that's it that is the idea behind

T Snee the key idea even though there

was seemingly a lot of math here the key

idea is really that t Snee is looking on

an individual data point by data point

basis and here we can have a quick

discussion on how it's different than

PCA TC is more complicated than PCA it's

in it's asking for more it's saying not

only do I care about General Trends in

your data set like PCA does PCA remember

is talking about what is the direction

of the maximum variance of your data set

I'm going to choose that as my first

principal component then what's the next

dimension of the highest variance of

your data set that's kind of looking on

a global level about what's the variance

of your entire data set T Snee is much

more zoomed in it's looking on a

individual I and J data point level and

trying to enforce that local structure

there so it typically does a lot better

job of clustering of making sure that if

two data points were close in the high

dimension they're close in this lower

dimension

but it also comes with that added

computational complexity because we do

need to care about things on a

pair-by-pair basis it's going to take a

lot longer for teeth need to run on the

same data set than PCA

because PCA at the end of the day even

though it is a bit complicated is just

doing a bunch of these linear

Transformations on your data and that

brings us the final point for this video

is that PCA is a linear method as much

as it's going on in PCA it's just doing

linear Transformations it's assuming

linear correlations and so it works

really well for linear data

batistney has no such assumptions it's

again just looking at pairs of data

points makes no assumption about

linearity and therefore it can work a

lot better when your data set is not

linear so hopefully you enjoyed this

video hopefully you learned a lot better

than you did before about how TC works

if you have any questions or comments

please leave them in the section below

thank you so much for watching like And

subscribe for more videos just like this

I'll catch all you wonderful people next

time
