3847 Spectrum | Behind the Bumpers | FRC CRESCENDO Robot

Summary

In this video, team 3847 Spectrum from FIRST Texas discusses their award-winning robot's features. They highlight their efficient intake system with silicone-wrapped rollers and Teflon wedges for precise note centering. The robot's pass-through mechanism feeds notes to a launcher with vertical compression and adjustable spin. The versatile amp and trap mechanism allows scoring in both game elements. Additionally, the team's climbing mechanism is detailed, along with their programming that incorporates vision systems for localization and consistent autonomous performance. The video also promotes Kettering University's Co-op employment programs and FIRST scholarships.

Takeaways

• 🤖 The team discusses their robot's pivoted shooter and trap mechanism, highlighting its effectiveness in competitions.
• 🏆 The team is a winner of the Bellon District Event and a finalist at the Houston District Event.
• 🎥 The video is sponsored by viewers and partners, with a special focus on Kettering University's Co-op employment programs.
• 💰 Kettering University offers a robotic scholarship worth up to $5,000 a year for tuition assistance.
• 🤝 The team encourages viewers to support content creators through YouTube memberships, which fund the correspondents.
• 🔄 The robot features an intake system with silicone-wrapped rollers and 3D printed Teflon wedges for note centering.
• 🔧 The launcher mechanism includes a sector gear, steel-enforced sealed plates, and anti-mark stealth wheels for precision.
• 🎯 The team's robot can score in both the amp and trap, utilizing a versatile mechanism for multiple game objectives.
• 🤓 The robot is equipped with a vision system using four Lime lights for localization and accurate shooting.
• 📊 The programming includes odometry for autonomous operation, ensuring consistent performance without localization data.
• 🏁 The team's success is celebrated, and they are excited to continue their journey in the First Texas dcmp.

Q & A

What is the primary function of the robot's intake mechanism described in the script?

The intake mechanism is designed to pick up game pieces, with two rollers wrapped in silicone to center the notes. It also includes 3D printed wedges with Teflon to assist in centering and full-width intake for easier and smoother intake.

How does the robot's pass-through mechanism work to transfer the game piece to the launcher?

The pass-through mechanism involves a feeder with two silicone-covered polycarb rollers that intake the game piece and transfer it to the launcher, which is controlled by a sector gear at the bottom reinforced with steel plates.

What material is used for the robot's launcher and what are its dimensions?

The launcher is made of steel and has dimensions of 13 and 1/2 inches wide with 38 inches of vertical compression.

How does the robot's amp and trap mechanism function?

The amp trap mechanism can score in both the amp and the trap. It uses roller silicone-wrapped polycarb tubes to feed the game piece back down and up through the backpack, making a U-turn into the amp or trap, with a powered cap to push the note down.

What is the purpose of the powered cap in the amp trap mechanism?

The powered cap is used to push the game piece down into the amp or trap, ensuring that it can go in both places despite the different angles.

Can you describe the robot's climbing mechanism as mentioned in the script?

The climbing mechanism is an elevator type with a chain system. The robot hooks onto the chain, drives into it, and pulls itself up to climb, using the same mechanism to also raise the trap.

What programming elements does the robot utilize for autonomous operation?

The robot uses four Limelight cameras, three encoders, and one absolute encoder for localization to determine its position on the field. It also uses odometry for autonomous positioning without localization data.

How does the robot's vision system contribute to its performance?

The vision system, with Limelight cameras, helps the robot make consistent shots by localizing its position on the field, while the absolute encoder on the launcher provides accurate positioning for the pivot angle.

What is the significance of the silicone wrapping on the intake rollers?

The silicone wrapping on the intake rollers helps to center the game pieces, which is crucial for accurate and reliable intake.

What is the purpose of the Teflon on the 3D printed wedges?

The Teflon on the 3D printed wedges is used to reduce friction and help center the game pieces during the intake process.

How does the robot's launcher mechanism ensure consistent shots?

The launcher mechanism uses a sector gear at the bottom reinforced with steel plates to control the angle with minimal slop, ensuring consistent shots.
