PRIME 4+ Feature Overview and Getting Started Guide
Summary
TLDRThe Denon DJ Prime 4 plus is a cutting-edge, standalone four-deck DJ console featuring a 10-inch multi-gesture touchscreen, Wi-Fi streaming access, and a professional mixer. It offers a customizable interface, advanced performance pads, and effects for creative DJing. The console supports various media sources and integrates with lighting systems for synchronized performances. The included Engine DJ software simplifies playlist management and syncs seamlessly with the hardware for an enhanced DJ experience.
Takeaways
- 🎛️ The Denon DJ Prime 4 plus is a standalone, four-deck professional DJ console with a 10-inch multi-gesture touchscreen.
- 📡 It offers Wi-Fi access to top music streaming partners and an independent Zone output for versatile performance setups.
- 🔍 The multi-touch, multi-gesture screen serves as the primary interface for navigating music libraries, loading tracks, and viewing waveforms.
- 🎧 A fully-featured 4-channel pro DJ mixer section provides expressive EQ control, sweep effects, and filter capabilities.
- 🔄 The transport control section includes familiar performance features like play, cue, sync, and looping, with a standardized layout.
- 🎚️ Six-inch touch capacitive jog wheels and long-throw pitch faders cater to all DJ styles, enhancing creative performance.
- 🎵 The dedicated Zone output allows sending different songs or playlists to separate rooms or areas during performances.
- 🔌 Connection to media sources is possible via USB, SD card, or SATA drive, offering flexibility in how DJs manage their music files.
- 📚 The engine DJ desktop app facilitates the transfer of playlists from Serato, Traktor, and Apple Music libraries to the Prime 4 plus in standalone mode.
- 📡 Engine Remote Library enables wireless connection of a computer to access the entire engine DJ music library for performance preparation.
- 🎨 The Prime 4 plus supports lighting integration and control for smart fixtures like nanoleaf, Philips Hue, and DMX, enhancing the visual aspect of performances.
Q & A
What is the Denon DJ Prime 4 plus?
-The Denon DJ Prime 4 plus is a four-deck standalone professional DJ console with a 10-inch multi-gesture touchscreen, Wi-Fi access, and an independent Zone output, designed for creative performance and effects workflow.
What are the key features of the Prime 4 plus's multi-touch, multi-gesture screen?
-The multi-touch, multi-gesture screen serves as an interface for navigating music libraries, searching and loading tracks, and viewing waveforms and other essential track data. It offers multiple waveform options and can be tailored to fit unique performance styles.
How does the 4-channel pro DJ mixer section of the Prime 4 plus enhance performance?
-The 4-channel pro DJ mixer section offers multi-assignable inputs, expressive EQ control, quick and easy sweep effects and filters, crossfader queuing, and headphone control, providing a comprehensive setup for DJs.
What are the capabilities of the transport control section of the Prime 4 plus?
-The transport control section offers familiar performance features such as play, cue, sync, and looping features, with a standardized layout for ease of use by all DJs.
How do the performance pads on the Prime 4 plus contribute to creative performances?
-The performance pads offer hot cue, loop, saved loop, roll, sampler, slicer, and slicer loop modes, providing ultra-responsive options for creative manipulation of music during performances.
What is the purpose of the dedicated Zone output on the Prime 4 plus?
-The dedicated Zone output allows DJs to send a different song or playlist to a separate room or area, enhancing the flexibility of audio distribution during performances.
How can users connect their Prime 4 plus to audio playback systems?
-Users can connect speakers to the chosen audio outputs at the rear of the Prime 4 plus for audio playback.
What are the different media sources that can be connected to the Prime 4 plus?
-Media sources can be connected via USB at the top or rear of the unit, an SD card insert at the top panel, or a SATA drive connected in the underside bay of the Prime 4 plus.
How does the engine DJ desktop app facilitate playlist management for the Prime 4 plus?
-The engine DJ desktop app allows DJs to save playlists to a USB drive or SD card and play them in standalone mode on the Prime 4 plus. It supports adding songs from various sources and importing entire collections.
What is the process for connecting the Prime 4 plus to streaming services like Amazon Music Unlimited?
-After connecting to Wi-Fi, users can select streaming partners from the source icon on the main screen. For Amazon Music, users need to log in and enter a confirmation code on a separate device to access over 100 million tracks.
How do the dynamic effects options on the Prime 4 plus contribute to performance creativity?
-The Prime 4 plus offers multiple dynamic effects options, including sweep effects, main effects, and touch effects, which can be used individually or layered for creative performances. The effects can be controlled through various knobs and touchscreen interactions.
What are the different performance pad modes available on the Prime 4 plus?
-The Prime 4 plus features seven performance pad modes: hot cue, manual loop, auto loop, roll, sampler, slicer, and slicer loop, offering a range of options for DJs to manipulate tracks during performances.
How can lighting integration and control be managed with the Prime 4 plus?
-The Prime 4 plus supports lighting integration and control for nanoleaf, Philips Hue, and DMX fixtures. Users can connect smart lights to the same Wi-Fi network and control them directly from the Prime 4 plus, with lighting following the beat of the music.
Outlines
🎧 Introduction to Denon DJ Prime 4 Plus
The Denon DJ Prime 4 Plus is a state-of-the-art, standalone DJ console with four decks, a 10-inch multi-gesture touchscreen, and Wi-Fi capabilities for music streaming. It offers a unique performance and effects workflow, with a professional DJ mixer section that includes assignable inputs and a range of controls. The console is designed to accommodate various DJ styles with its transport control section, jog wheels, and pitch faders. It also features a dedicated Zone output for separate room audio and dual microphone inputs. To set up, connect power and audio outputs, adjust the touchscreen, and connect media sources via USB, SD card, or SATA drive. The Engine DJ desktop app facilitates the transfer of playlists and tracks from Serato, rekordbox, and Apple Music libraries to the Prime 4 Plus for standalone play.
🔄 Connecting and Streaming Music Services
The Denon DJ Prime 4 Plus allows for connection to various streaming services, including Amazon Music Unlimited, which hosts over 100 million tracks. Users can log in and access their personal playlists, charts, and recommendations. The console also supports searching the entire streaming database using the touchscreen or an external keyboard. Tracks can be loaded onto decks with buffered playback for uninterrupted performance. Additionally, the Prime 4 Plus offers dynamic effects options, such as sweep, main, and touch effects, which can be layered for creative performances. The touch effects feature uses the 10-inch screen as an XY controller, providing a tactile interface for effect manipulation.
🎛 Exploring Performance Pad Modes and Lighting Integration
The Prime 4 Plus is equipped with performance pads that offer multiple modes, including hot cue, manual loop, auto loop, roll, sampler, slicer, and slicer loop. These modes enhance the DJ's ability to create dynamic mixes and effects. The console also integrates with smart lighting systems like nanoleaf and Philips Hue, allowing for wireless control and synchronization with the music being played. For DMX fixtures, a micro DMX dongle can be connected to the Prime 4 Plus for advanced lighting control, including auto loops and color overrides.
📚 Final Thoughts and Additional Resources
The Denon DJ Prime 4 Plus is a comprehensive DJ solution that combines advanced hardware with software features for a seamless music mixing experience. It provides extensive control over music playback, effects, and lighting, making it suitable for a wide range of DJ performances. For further guidance, the user manual is available on denondj.com, and enginedj.com offers the latest information and guides on using the Prime 4 Plus and its features.
Mindmap
Keywords
💡Denon DJ Prime 4
💡Multi-gesture touch screen
💡Wi-Fi access
💡Performance pads
💡Dedicated Zone output
💡Engine DJ operating system
💡Serato
💡Streaming services
💡Effects
💡Lighting integration
💡Mixer section
💡Jog wheels
Highlights
The Denon DJ Prime 4 plus is a four deck standalone professional DJ console with a 10 inch multi-gesture touch screen.
It offers Wi-Fi access to top music streaming partners and an independent Zone output.
The console features an ever-expanding set of professional features thanks to its regularly updated engine DJ operating system.
The multi-touch, multi-gesture screen serves as an interface for navigating music libraries, searching, loading tracks, and viewing waveforms.
Shift and view button combinations allow for multiple waveform options, tailoring the screen to fit unique performance styles.
The 4 channel pro DJ mixer section includes multi-assignable inputs and expressive EQ control.
Quick effects and filter, crossfader queuing, and headphone control are part of the mixer section.
Transport control section provides familiar performance features for DJs, including play, sync, and looping.
Six-inch touch capacitive jog wheels and long-throw pitch faders are designed for all DJ styles.
Ultra-responsive performance pads offer various creative modes such as hot cue, loop, roll, sampler, slicer, and slicer loop.
Dedicated Zone output allows sending different songs or playlists to separate rooms.
Dual microphone inputs and control enhance performance capabilities.
Engine DJ desktop app is ideal for DJs with established music libraries, allowing playlist management and standalone play.
Engine remote Library enables wireless connection to a computer's entire music library for track preparation.
Built-in Wi-Fi on the Prime 4 plus provides access to over 100 million tracks on Amazon Music Unlimited and other streaming services.
The console features multiple dynamic effects options including sweep, main, and touch effects for creative performances.
The touch effects feature uses the 10-inch touchscreen as an XY controller for various effects.
Seven performance pad modes are available for enhanced DJ performance interactivity.
Lighting integration and control for smart fixtures like nanoleaf and Philips Hue add visual elements to performances.
The Prime 4 plus also supports DMX control for professional lighting setups.
The full hardware user guide and information on engine DJ can be found online for further guidance and exploration.
Transcripts
welcome to the Future overview video for
the Denon DJ Prime 4 plus the Prime 4
plus is a four deck Standalone
professional DJ console with a 10 inch
multi-gesture touch screen Wi-Fi access
to top music streaming Partners
independent Zone output an unparalleled
creative performance and effects
workflow and an ever expanding set of
professional features thanks to its
regularly updated engine DJ operating
system
the Prime 4 pluses multi-touch
multi-gesture screen is your interface
to navigating your music library
searching and loading tracks and viewing
waveforms and other essential track data
and workflow with multiple waveform
options available by holding shift and
pressing the view button you'll be able
to tailor the screen to fit your unique
performance style the fully featured 4
channel pro DJ mixer section offers
multi-assignable inputs expressive EQ
control quick and easy to use sweep
effects and filter plus crossfader
queuing and headphone control the
transport control section offers a
familiar performance area for all DJs
with play Q sync and looping features
and standardized layout the six inch
touch capacitive jog wheels and long
throw pitch faders are perfect for all
DJ Styles and for Creative performers
Ultra responsive performance pads offer
hot cue Loop saved Loop roll sampler
slicer and slicer Loop modes while
performing you can send a different song
or playlist to a separate room or area
with the dedicated Zone output and
easily handle any gig with dual
microphone inputs and Control Plus
elevate your performance and manipulate
your music with a bank of powerful Pro
DJ effects to get started connect the AC
cable and power up the unit
[Music]
for audio playback connect speakers to
your chosen audio outputs at the rear
raise the Prime 4 plus 10 inch
touchscreen to the required viewing
angle securing position with the metal
support
connection to your media sources
containing your music files can be via a
choice of USB connection to at the top
of the unit two at the rear
SD card insert at the top panel or a
SATA drive connected in the underside
Bay of the Prime 4 plus
now it's time to add some music
[Music]
for DJs with established Serato record
box Tractor and apple music libraries
the engine DJ desktop app is the ideal
solution to saving playlists to a USB
drive or SD card and playing them in
Standalone mode on the Prime 4 plus go
to engine dj.com to download the latest
version of engine DJ desktop
then click the plus sign by collection
to create a new playlist
use the file folder icon to select songs
saved on your computer then drag them
over to your newly created playlist
foreign
you can also select the Serato record
box Tractor and apple music icons to add
songs crates or playlists from these
sources
you can also import your entire
collection from these sources by
selecting them right-clicking on the
collection header and then selecting
import collection once your playlists
are added click on sync manager and
select the playlist that you want to
export
then select your USB or SD card from the
drop down in the upper right hand corner
you may also export your playlist to
your personal Dropbox folder using the
same method once your drive is selected
click export to drive once the export is
complete eject your drive and insert it
into your Prime 4 plus
[Music]
the drive will automatically connect and
your playlists and tracks will be
instantly available
you can also sync any hot cues loops and
other information added while performing
back to your engine DJ desktop Library
by inserting your drive opening the sync
manager and clicking sync to engine DJ
engine remote Library allows you to
wirelessly connect your computer as a
source giving you access to your
computer's entire engine DJ music
library this is a great way to prep
tracks for performances using your
Hardware to quickly add cue points and
Loops to connect to your computer with
engine remote Library make sure your
computer and your DJ Hardware are both
connected to the same Wi-Fi network to
connect to Wi-Fi on the Prime 4 plus
swipe down from the top of the screen to
access the main menu
here you'll have access to a number of
performance settings media sources Wi-Fi
connectivity internal recording and
lighting control
select Wi-Fi and connect to your network
next open up ngdj on your computer make
sure that you have the latest version
installed navigate to The Source menu on
the primeport plus and select your
computer from the list
on your computer accept a confirmation
request now you'll be able to access all
of your ngdj playlists and songs
directly on the Prime 4 plus any changes
that you make to cue points and Loops
will be automatically saved to your
computer's engine DJ Library
you can also utilize the built-in Wi-Fi
on the primeport plus to access over 100
million tracks on Amazon Music Unlimited
and other top streaming services
once connected to Wi-Fi tap the source
icon in the upper left corner of the
main screen here you can select from all
available streaming Partners as well as
any inserted USB or SD cards in this
example we'll select Amazon music if
this is your first time logging into
Amazon music you'll be prompted to enter
confirmation code on a computer or
mobile device
visit the address specified on the
screen log into your Amazon account and
enter the six digit code
once confirmed the Prime 4 plus will
connect to Amazon Music Unlimited
here you'll have access to over 100
million CD quality tracks including your
personal playlists charts
recommendations and more
you can also search the entire Amazon
music unlimited streaming database using
the touchscreens keyboard or a connected
USB keyboard
[Music]
once you select a track use one of the
load buttons or press the library knob
then select the deck you want to load
the song to
[Music]
the song will buffer into the internal
memory for uninterrupted playback
if you have a compatible USB or SD card
inserted into the Prime 4 plus be ET
grid Q Loop and waveform data will be
saved for each track along with play
State status
[Music]
the Prime 4 plus features multiple
Dynamic effects options including sweep
effects main effects and touch effects
each of these effects options can be
used on their own or layered with each
other for ultimate creativity
The Sweep effects are controlled by
turning the dedicated sweep effects knob
on each Channel either clockwise or
counterclockwise
at the 12 o'clock position the effect is
off
effect options are selected by pressing
the desired sweep effects button on the
lower mixer section of the Prime 4 plus
sweep effects options include filter
[Music]
Echo
[Music]
[Music]
[Music]
thank you
[Music]
wash
[Music]
[Music]
foreign
[Music]
[Music]
both Echo and wash are post-fader
effects which means they will Trail off
after the volume fader is down
Echo wash and noise soup effects are
only available for Standalone and
streaming tracks when an external source
is connected to the Prime 4 plus the
sweep effects knobs function as a high
pass low-pass filter
the Prime 4 plus features over 25 Main
effects which can be selected from both
the FX1 section and the FX2 section
these can be assigned to each Channel
with the assignment buttons above the
gain knobs turn the select knob to
choose an effect to engage press the FX
on button
depending on the effects selected there
will be additional parameter adjustments
options available by turning the
parameter knob
press the param button below this knob
to reset the setting to its default
[Music]
the effect frequency can also be
adjusted by turning the frequency knob
this applies the effect to a specific
frequency range
press the reset button to return the
setting back to its default
use the Beats left and right buttons to
change the beat division for the effect
[Music]
the wet dry knob adjusts the level of
the main effects in the mix
[Music]
foreign foreign
the touch effects feature transforms the
10 inch touchscreen to an XY controller
for various effects options
to access touch effects tap the touch
effects icon on the top of the screen
select a touchfx option by tapping FX
select in the lower left hand corner
then choose an option from the list
the type of effect controlled by the X
and Y axis will vary depending on which
touch effects is selected
some touch effects also include a
resonance adjustment option that can be
changed by dragging the slider on the
bottom of the screen choose which deck
to apply the effect to by tapping the
deck number in the upper left hand
corner
you'll be able to see the moving
waveform of the selected deck in the
upper right hand corner
to activate an effect simply touch the
screen and drag your finger around to
alter the effect parameters
to latch the effect to a specific area
of a touch screen select the latch
option
this allows you to select a specific
touch effects combination while freeing
up your hand for other performance needs
the Prime 4 plus features seven
performance pad modes including hot cue
manual Loop
Auto Loop
roll
sampler
slicer
and slicer Loop enable the performance
pad option in the layout section of the
menu to activate the performance pads
heads up display on the screen
this will allow you to view vital
performance pad information directly on
the screen such as hot cue and Sample
names as well as Loop and roll beat
divisions when using the hot cue mode
press an unassigned pad to set a cue
point in your track to jump to a cue
Point press a highlighted pad to delete
a cue Point hold shift and press the pad
you wish to delete
the set of manual Loop press the
unassigned pad to set the loop endpoint
then press the same pad again to set the
loop out point
in this mode you can jump between
multiple Loops by pressing each Loop's
assigned pad
hold shift and press the pad to delete
the loop
[Music]
in Auto Loop mode press a pad to
automatically create a loop each pad
represents a different Loop length
foreign
press the pad again to disengage the
loop
Auto Loop and manual Loop controls can
also be accessed with a loop encoder and
in and out buttons on each deck
turn the encoder knob to select the auto
Loop length which is visible next to the
track on the title screen to activate
the auto Loop press the loop encoder
knob
while the loop is active turning this
knob shortens or lengthens The Loop
press the knob again to exit the loop
while the loop is engaged you can turn
it into an active Loop by first saving
it by pressing an available manual Loop
pad then holding the left parameter
button and pressing the saved pad
this will cause the track to
automatically Loop when the active Loop
section is reached in the waveform this
is perfect for automatically creating
intros and outros and songs
holding the left parameter button and
pressing the pad again will turn the
loop back into a normal Loop
the roll mode allows you to Loop a
section of a track while not altering
the song's playback position when
pressing the pad the song will Loop but
upon releasing the pad the song returns
to its normal playback position with the
sampler mode you're able to add drops
effects and other samples to your mix
with the embedded sampler by default the
sampler is routed to the main audio
output you can change the output to
specific Channel instead by accessing
the settings menu and navigating to the
mixer tab
foreign by setting the sampler output to
a channel you'll be able to add FX and
EQ to your samples as well as have
control over the volume with that
Channel's volume fader
[Music]
when the sample output is set to the
main output you can adjust the volume
using the sampler volume slider in the
control center
to load a sample to a slot select the
track or sample from your music library
or the pre-loaded sampler Content
Library and press the browse now
[Music]
then select which sampler slot you'd
like to load the sample to on the touch
screen
to trigger the sample enter the sampler
pad mode by double pressing the roll pad
mode button and press the desired
performance pad slot the slicer mode
allows you to chop up the Beats of a
track by jumping to or repeating a
specific beat
[Music]
the slicer Loop mode functions the same
way but focuses on a loop section
instead of the entire track
foreign
[Music]
4 plus features lighting integration and
control for nanoleaf Philips Hue and DMX
fixtures both nanoleaf and Philips Hue
function completely wirelessly in this
example we'll connect to some nanoleaf
lights
to start ensure that your nanoleaf
lights are plugged into power and
connected to the same Wi-Fi network as
your Prime 4 plus then swipe down access
lighting from the main menu or double
tap the view button
select basic or Advanced controls then
select the type of smart lights that you
want to connect to
hold the power button on your nanoleaf
controller for five to seven seconds
once the flash sequence starts press
pair on the screen of your Prime 4 plus
once the lighting is connected you'll
have access to color controls and Chase
sequences on the screen of the Prime 4
plus the lighting will follow the beat
of the track you're playing this
includes both streaming tracks and songs
from USB drives or SD cards
you can quickly navigate in and out of
the lighting menu during your
performance by double tapping the view
button
which micro DM dongle or control 1. in
this example we'll use the micro DMX
dongle
be sure that your desired sound switch
project is exported to your USB or SD
card and is inserted into one of the
Prime 4 plus media slots
connect the micro DMX dongle to the DMX
cable next to your lights
then connect the other end to an
available USB slot on the Prime 4 plus
in addition to following existing sound
switch scripting of music in your
library you'll now have access to Auto
Loops for streaming and saved media
tracks as well as color overrides
strobing static looks moving head
positions and more
thank you
[Music]
[Music]
that should be enough to get you started
with your Denon DJ prime4 plus remember
the full hardware user guide is
available in the download section of
denondj.com to learn more about engine
DJ and the various features it brings to
the Prime 4 plus just head over to
engine dj.com for the latest information
and guides
Посмотреть больше похожих видео
Best DJ Gear for Every Budget!
Dj Chicken Attack Davido as Davido Bouncer Stop him From Touching Davido in Surulere Lagos
Dune HD Pro One 8K Plus | The NEW Best In-Home Streaming Media Player?
Is This $400 SDI Video Switcher Any Good? - OSEE Duet Review
If I had 0 Instagram Fans for my Music, I'd do THIS (DJs & Music Producer)
The PERFECT TDS Loadout.
5.0 / 5 (0 votes)
