ionization of air surrounding the high
voltage transmission lines causing the
conductors to Glow producing a hissing
noise is called Corona discharge or
Corona effect Corona effect in
transmission lines this phenomenon
occurs when the electrostatic field
across the transmission line conductors
produces the condition of potential
gradient the air gets ionized when the
potential gradient at the conductor
surface reaches the value of 30 KV by CM
at normal pressure in temperature in
transmission lines conductors are
surrounded by the air
air acts as a dialectric medium when the
electric field intensity is less than 30
KV by CM the induced current between the
conductor is not sufficient to ionize
the air however when the voltage of air
surrounding the conductor exceeds the
value of 30 KV by CM the charging
current starts to flow through the air
that his air has been ionized the
ionized air Act is a virtual conductor
producing a hissing sound with a
luminous Violet glow there is a hissing
noise with Violet glow phenomenon termed
as Corona effect which is commonly
observed in high voltage transmission
lines the corona effects leads to high
voltage drop and energy loss along with
release of Ozone gas there is a need to
be aware of this phenomenon and its
effects on the transmission system a
Corona discharge is an electrical
discharge caused by the ionization of a
fluid such as air surrounding a
conductor carrying a high voltage it
represents a local region where the air
has undergone electrical breakdown and
become conductive allowing charge to
continuously leak off the conductor into
the air
Corona Rings also known as grading Rings
or anti-c Corona rings are specialized
devices installed on high voltage
transmission lines to control the
electric field distribution and mitigate
the corona effect these rings are
typically mounted on the hardware of
transmission line Towers such as
insulator strings or support structures
and are strategically positioned along
the length of the line the primary
purpose of Corona Rings is to modify the
electric field surrounding the
conductors in order to reduce the
intensity of the electric field at
critical points and minimize the
likelihood of Corona
discharge Corona rings are typically
constructed from materials with high
electrical conductivity and corrosion
resistance such as aluminum or copper
they are often shaped as concentric
Rings or cylinders with smooth surfaces
to facilitate the desired redistribution
of electric field lines Corona Rings
play a critical role in controlling
Corona discharge and optimizing the
performance of high voltage transmission
transmission
lines understanding their function and
design occurs when energy is dis ated as
a result of the corona effect in high
voltage transmission lines these losses
manifest as heat and light energy due to
the ionization of air surrounding the
conductors Corona loss is the other
major type of power loss in transmission
lines essentially Corona loss is caused
by the ionization of air molecules near
the transmission line
conductors these Coronas do not spark
across lines but rather carry current
hence the loss in the air along the wire
Corona discharge and transmission lines
can lead to hissing cackling noises a
glow and the smell of ozone generated
from the breakdown and recombination of
o2
molecules the color and distribution of
this glow depends on the phrase of the
AC signal at any given moment in time
positive Coronas are smooth and blue in
color while negative Coronas are red and
spotty Corona loss only occurs when the
line toline voltage exceeds the corona
threshold unlike resistive loss which
were amount of power lost was a fixed
percentage of input the percentage of
power loss due to Corona is a function
of the Signal's voltage
Corona discharge power losses are also
highly dependent on the weather and
temperature Theory the corona Factor
equation was empirically derived by FW
Peak and published in
1911 in a later publication he modified
the original equation and he showed that
the total amount of power loss in a wire
due to the corona effect was equal to
the equation the radius of the conductor
has a large effect on the total amount
of Corona loss one way of getting lines
with the larger effective radius is
through the use of bundles where two to
six separate but close lines are kept at
the same voltage via intermittent
connectors this reduces the amount of
metal needed to achieve a given radius
and Corona loss factors affecting Corona
the phenomenon of Corona is affected by
the physical state of the atmosphere as
well as by the conditions of the line
the following are the factors upon which
Corona depends conductor size the corona
effect depends upon the ship and
conditions of the conductors the rough
and irregular surface will give rise to
more Corona because unevenness of the
surface decreases the value of breakdown
voltage thus a stranded conductor has
irregular surface and hence gives rise
to more Corona than a solid conductor
spacing between conductors if the
spacing between the conductor is made
very layer as compared to their
diameters there may not be any Corona
effect it is because layer distance
between the conductors reduces the
electrostatic stresses at the conductor
surface thus avoiding Corona formation
Supply voltage as the electrical Corona
discharge mainly depends upon the
electric field intensity produced by the
applied system voltage
voltage therefore if the applied voltage
is high the corona discharge will cause
excessive Corona loss in the
transmission lines on contrary the
corona is negligible in the low voltage
transmission lines due to the inadequate
amount of electric field required for
the breakdown of air conductor surface
the corona effect depends upon the shape
material and conditions of the
conductors the rough and irregular
surface IE unevenness of the surface
decreases the value of breakdown voltage
this decrease in Breakdown voltage due
to concentrated electric field at Rough
spots give rise to more Corona effect
the roughness of conductor is usually
caused due to the deposition of dirt
dust and scratching raindrops snow fog
and condensation accumulated on the
conductor surface are also sources of
surface irregularities that can increase
Corona air density Factor air density
Factor also determines the corona loss
in transmission lines the corona loss
and inversely proportional to air
density Factor power loss is high due to
Corona in transmission lines that are
passing through a hilly area because in
a hilly area the density of air is low
spacing between conductors design
Engineers calculate the spacing between
the two conductors in the transmission
line after careful and extensive
research as the phenomenon of Corona
discharge is affected by the conductor
spacing if the distance between two
conduct conductors is very large as
compared to the diameter of conductor
the corona effect may not happen it is
because the larger distance between
conductors reduces the electrostatic
stress at the conductor surface thus
avoiding Corona
formation atmosphere as Corona is formed
due to ionization of air surrounding the
conductors therefore it is affected by
the physical state of
atmosphere in the stormy weather the
number of ions is more than normal
weather the decrease in the value of
breakdown voltage is followed by the
increase in the number of
ions as a result of it Corona occurs at
much less voltag as compared to the
breakdown voltage value in Fair weather
methods for reducing Corona losses the
corona loss can be reduced by using
conductors with large diameters the
voltage at which the corona occurs can
be increased by increasing the size of
the conductor and hence the corona loss
can be reduced Hollow conductors these
are used to increase the effective
diameter of the conductor without using
any additional material since Corona
loss is inversely proportional to the
diameter of the conductor Corona loss
decreases with an increase in the
diameter bundled conductors these are
made up of two or more subconductors and
is used as a singlephase
conductor optimized conductor design
increasing the diameter of conductors or
bundling multiple smaller conductors
together reduces the electric field
intensity around the conductors lowering
the likelihood of Corona discharge and
minimizing Corona losses control
electric field distribution installing
Corona Rings or grading rings at
strategic locations along the
transmission line helps redistribute the
electric field reducing its intensity at
critical points and mitigating Corona
discharge thereby minimizing Corona CES
improve insulator performance using
insulators with higher pollution
flashover performance and better
contamination resistance helps mitigate
the effects of Corona discharge on
insulator surfaces reducing surface
leakage current and Corona Lo losses
optimize transmission line routing
planning the route of transmission lines
to avoid areas with high pollution
levels or adverse environmental
conditions minimizes surface
contamination on insulators thereby
reducing the risk of Corona discharge
and Associated Corona losses increase
conductor size using conductors with
larger diameters reduces the electric
field intensity around the conductors
lowering the likelihood of Corona
discharge and minimizing Corona losses
additionally increasing the size of
conductors reduces the surface current
density which can contribute to Corona
formation how Corona effect is reduced
it has been observed that the intense
Corona effects are observed at a working
voltage of 33 KV or above on the
substations are bus bars rated for 33 KV
and higher voltages highly ionized air
may cause Flash over in the insulators
or between the phases causing
considerable damage to the equipment if
careful designing is not made to reduce
the corona effect the corona effect can
be reduced by the following methods by
increasing conductor size the voltage at
which Corona occurs can be raised by
increasing conductor size hence the
corona effect may be reduced this is one
of the reasons that acsr conductors
which have a larger cross-sectional area
are used in transmission lines by
increasing conductor spacing the corona
effect can be eliminated by increasing
the spacing between conductors which
raises the voltage at which Corona
occurs however increase in conductor
spacing is limited due to the cost of
supporting structure as bigger cross
arms and supports to accompany the
increase in conductor spacing increases
the cost of transmission system by using
Corona ring the intensity of electric
field is high at the point where the
conductor curvature is sharp therefore
Corona discharge occurs first at the
sharp points edges and Corners in order
to mitigate electric field Corona rings
are employed at the terminals of very
high voltage equipment Corona rings are
metallic rings of to oil shaped which
are fixed at the end of bushings and
insulator strings this metallic ring
distributes the charge across a wider
area due to its smooth round shape which
significantly reduces the potential
gradient at the surface of the conductor
below the critical disruptive value and
thus preventing Corona
discharge advantages of Corona losses
limitation of voltage surges Corona
discharge can help dissipate excess
energy and limit the amplitude of
voltage surges is caused by lightning
strikes or switching operations thus
protecting the transmission line
equipment from damage reduction of
audible noise while Corona discharge
produces audible noise the presence of
Corona can reduce the noise generated by
wind induced conductor
vibrations this is because Corona can
stabilize the electric field around the
conductors minimizing disruptive
vibrations disadvantages of Corona
losses energy losses Corona losses
result in the conversion of electrical
energy into heat and light leading to
reduced efficiency in the trans
system this translates to higher
operating costs and decreased overall
system
efficiency insulation damage intense
Corona discharge can cause degradation
and erosion of insulator surfaces
compromising their effectiveness and
increasing the risk of flashover which
can lead to power outages and Equipment
damage a nonsinusoidal voltage drop
occurs in the transmission line due to
nonsinusoidal Corona current which
causes interference with neighboring
communication circuits due to
electromagnetic transients and
electrostatic induction effects
Ozone gas is produced due to the
formation of Corona which chemically
reacts with the conductor and causes
corrosion the energy dissipated in the
system due to Corona effect is called as
Corona loss the power loss due to Corona
is undesirable and
uneconomical the efficiency of
transmission line is highly reduced due
to the loss of power or energy Corona
losses in transmission lines occur due
to the ionization of the air surrounding
the conductors which results in the
dissipation of energy here's a more
detailed explanation of how Corona
losses happen in transmission lines
electric field formation at the high
voltage is used in transmission lines
typically above 1110 KV the electric
field around the conductors becomes very
intense the electric field strength is
highest at the surface of the conductors
or it can exceed the dialectric strength
of the surrounding air air ionization
when the electric field strength exceeds
the dialectric strength of the air the
air becomes ionized meaning that the air
molecules are split into positively and
negatively charged particles this
process is called Corona discharge or
Corona effect energy dissipation the
ionized air particles collide with
neutral air molecules transferring some
of their kinetic energy to the neutral
molecules this transfer of energy
results in the dissipation of power
which is known as Corona loss or Corona
discharge loss factors affecting Corona
losses conductor size and surface
condition smaller conductors or
conductors with a regular surfaces tend
to have higher electric field gradients
leading to increased Corona losses
transm voltage higher transmission
voltages generally result in higher
Corona losses as the electric field
strength is proportional to the voltage
whether conditions factors such as
humidity air pressure and precipitation
can affect the ionization of the air and
the magnitude of Corona losses
consequences of Corona losses reduce
transmission efficiency the energy loss
due to Corona discharge represents a
portion of the power that is not
delivered to the load reducing the
overall transmission
efficiency increased operating costs the
energy loss to the corona discharge
needs to be compensated by generating
additional power leading to higher
electricity generation and transmission
costs potential for interference Corona
discharge can generate audible noise and
electromagnetic interference which can
impact nearby communication systems and
Equipment foggy weather brings a number
of challenges for power generation and
transmission Corona discharge fog
impacts power transmission and high
voltage Lines by causing Corona
discharge when fog surrounds the
conductors water droplets can accumulate
on the surface altering the electric
field around the lines this can lead to
Corona discharge where the air around
the conductors ionizes and forms a
conductive path for the
electricity Corona discharge results in
energy loss audible noise and can also
lead to increased wear on the
transmission equipment Corona effect
results in energy loss as it dissipates
the energy in form of Corona discharge
thus reducing the overall efficiency of
the power
transmission this Corona discharge also
produces audible noise which is
disruptive especially in residential
areas Corona discharge also results in
deterioration of insulators and
transmission lines over time thus
reducing their life and increased
frequency of Maintenance Transformer
cooling issues foggy conditions impede
the cooling of
Transformers Transformers dissipate heat
during operation and if the fog
restricts heat dissipation it could lead
to overheating and reduced
deficiency corrosion concerns high
humidity associated with fog contributes
to corrosion of metal components in
power generation and transmission
systems potenti Ally impacting the
longevity and performance of equipment
insulation challenges fog and high
humidity affects the insulating
properties of certain materials
potentially leading to electrical
insulation issues
関連動画をさらに表示
Transmission Line Distribution | ACSR | Insulator | Spacer | High Tension Line | SAG | Earthing
Praktikum Sistem Daya Elektrik Percobaan I (Transmisi Pendek)
Electricity Generation, Transmission, and Distribution | Grade 9 Science Quarter 4 Week 8
High Voltage Engineering क्या है ? Introduction of High Voltage Engineering #highvoltage #hve #viral
ATPL Meteorology - Class 13: Turbulence and Windshear.
What's Inside The Sun?
5.0 / 5 (0 votes)
