Comgrow T500, the only fast Klipper firmware 3D printer with a 500mm cube print volume, linear rails

Aurora Tech
24 Sept 202323:08

Summary

TLDRThe Aurora Tech Channel reviews the Congo t500, a large-scale 3D printer by Comgrow, a known reseller of Creality printers. With a 500mmΒ³ print volume and modular linear rails for motion, the t500 offers a rigid frame and fast printing speeds up to 180mm/s. Despite minor prototype quality issues, the printer demonstrates good print quality and potential, retailing around $900 with a 7-inch Clipper pad and 600W PSU. The review also highlights the printer's motion system, print speed, and quality, while noting areas for improvement.

Takeaways

  • πŸ˜€ The Congo t500 is a large 3D printer by Comgrow, a reseller known for selling Creality printers on Amazon.
  • πŸ—οΈ The t500 has a massive print volume of 500 millimeters cube, making it larger than any other reviewed printer.
  • πŸ› οΈ The printer features a modular linear rail motion system, dual Y and dual Z axes, and a solid aluminum gantry for enhanced rigidity.
  • πŸ”Œ The print surface is a spring steel sticker sheet, heated by a 600-watt PSU, and the machine runs on Clipper with a 7-inch touchscreen.
  • πŸ’» The 32-bit motherboard connects stepper motors and limit switches, with processing handled by the 7-inch pad, likely a Megabase 7 inch pad with a quad-core Cortex A53 processor.
  • πŸ”§ The extruder is a 6.5:1 ratio dual gear direct extruder, with a non-volcano style nozzle and three extra hardened steel nozzles.
  • πŸ“¦ The machine comes in a large box, weighing nearly 90 pounds, with all parts well protected and a simple assembly process.
  • πŸ“ˆ The print speed is fairly fast, with the ability to print at 180 millimeters per second and good print quality for a large bed printer.
  • 🌑️ The print bed heats up quickly with a 600-watt power supply, and the temperature difference across the bed is acceptable for its size.
  • πŸ›‘ Some issues were noted with the print surface sticking too well to PLA, requiring glue to improve adhesion, and the cooling system could be improved for better overhangs with larger nozzles.

Q & A

  • What is the Congo T500?

    -The Congo T500 is a large 3D printer that is a final prototype from ComGrow. It features a 500 millimeter cube print volume, making it larger than any other printer previously reviewed by the channel.

  • Who is ComGrow and what is their relationship with Creality?

    -ComGrow is one of Creality's resellers, known for selling thousands of Creality printers on Amazon. They have previously been reviewed for their laser engraver, the Z1, and the mini desktop CNC, with the T500 being their first 3D printer.

  • What are the key features of the Congo T500's motion system?

    -The motion system of the Congo T500 uses modular linear rails on the X, dual Y, and dual Z axes. It also includes two solid aluminum brackets at the back to enhance the rigidity of the tall gantry.

  • What is the print surface of the Congo T500?

    -The print surface of the Congo T500 is a spring steel sticker sheet, which is heated by a 600-watt PSU.

  • What software and hardware components does the Congo T500 use?

    -The Congo T500 runs Clipper and uses a 7-inch touch pad similar to a Sonic PAD as its touchscreen. The Linux OS and Clipper are installed on the pad, and a 32-bit motherboard is used to connect the stepper motors, limit switches, and the print head.

  • What are the specifications of the extruder on the Congo T500?

    -The extruder on the Congo T500 has a 6.5:1 ratio dual gear direct drive system. It comes with three extra hardened steel nozzles sized at 0.4, 0.6, and 0.8 millimeters.

  • What is the price range of the Congo T500?

    -The Congo T500 is priced at around $900.

  • What is Voxel PLA and how is it related to this review?

    -Voxel PLA is a brand created by a print farm in Southern California. It is a modified version of PLA that provides higher impact strength and supports high-speed printing. The brand sponsored today's video and is mentioned for its quality and reliability.

  • What are the assembly steps for the Congo T500?

    -The assembly involves placing the gantry on the base, reinforcing the gantry with brackets, mounting the spool holder on top, and attaching the screen bracket on the right side. The machine also requires connecting some cables and adjusting the local voltage with the power supply.

  • What are some of the pros and cons of the Congo T500 as mentioned in the review?

    -Pros include an excellent motion system, a super rigid frame, good print speed and quality, and a large heated print bed. Cons include issues with the print surface sticking too well to PLA, insufficient cooling when using a 0.8 millimeter nozzle, and some quality control issues with the prototype.

Outlines

00:00

πŸ€– Introduction to the Congo T500 3D Printer

The video begins with an introduction to the Congo T500 3D printer, a final prototype from Comgrow, a reseller of Creality printers. The T500 is Comgrow's first 3D printer and features a 500mm print volume, modular linear rails, and a 600-watt PSU. The machine runs on Clipper with a 7-inch touchpad and comes with various hardware components. Priced at around $900, it's positioned as a high-performance printer with a large build volume.

05:00

βš™οΈ Setting Up the Congo T500

The setup process of the T500 involves assembling the base, gantry, and print head, followed by attaching the 7-inch Clipper pad and other accessories. The video highlights the ease of assembly with top-mounted screws and the functionality of the Clipper interface. After setup, the auto-home and leveling processes are demonstrated, ensuring all components are functioning correctly. The printer is then tested with a simple Benchy print, which completes in 43 minutes, displaying decent quality with minimal stringing.

10:16

πŸ–¨οΈ Performance Tests and Print Quality

Various performance tests are conducted on the T500, including printing a number slider and a honeycomb box to assess clearance and retraction capabilities. The printer shows good results, though some stringing is noted. A comparison with other new-generation machines reveals that the T500 offers competitive print quality, especially at higher speeds. Further tests include printing a large lampshade with a 0.8mm nozzle, a PETG kitchen towel hanger, a TPU wallet, and a nylon carbon fiber part, all demonstrating the printer's versatility and capability.

15:18

πŸ‘ Pros and Cons of the Congo T500

The pros of the T500 include its excellent motion system, rigid frame, dual Z-axis support, fast print speeds, decent print quality, use of open-source Clipper firmware, and effective bed heating. However, cons include issues with the print surface adhering too well, limited maximum bed temperature, cooling inadequacies with larger nozzles, inconvenient filament sensor placement, and quality control issues in the prototype. Despite these issues, the printer is noted for its potential and good overall value.

20:19

πŸ“ Final Thoughts and Recommendations

The final section discusses the T500's potential for future recommendations, noting that Comgrow has addressed reported quality issues for large-scale production. While the prototype has some flaws, the T500's hardware and performance are promising. The video concludes with a cautious recommendation and a link to the product, inviting viewers to consider the T500 while acknowledging that further testing of production models is needed before a full endorsement.

Mindmap

Keywords

πŸ’‘Congo t500

The Congo t500 is a large-format 3D printer that is the focus of the video review. It is a final prototype from Comgrow, a reseller of Creality printers. The printer stands out for its size and capabilities, with a 500mm cube print volume, which is larger than any other reviewed by the channel. The machine's specifications and performance are central to the video's theme of evaluating 3D printing technology.

πŸ’‘Comgrow

Comgrow is a company that has been selling Creality printers on Amazon for many years and is the creator of the Congo t500. They are highlighted in the video as a reputable reseller with a history of selling quality 3D printing equipment. The mention of Comgrow establishes trust and context for the t500's introduction and review.

πŸ’‘3D Printer

A 3D printer is a device that creates three-dimensional objects from digital models by adding material layer by layer. In the context of the video, the 3D printer, specifically the Congo t500, is the main subject of the review, with its features, performance, and print quality being evaluated throughout the script.

πŸ’‘Print Volume

Print volume refers to the physical space within a 3D printer where objects can be printed. The Congo t500 boasts a large print volume of a 500mm cube, which is a key feature emphasized in the video, showcasing its capability to handle large-scale printing tasks.

πŸ’‘Linear Rails

Linear rails are components used in the motion system of the 3D printer to guide its axes, ensuring smooth and precise movement. The t500 uses modular linear rails on the X, dual Y, and dual Z axes, which contribute to its high build quality and printing accuracy, as mentioned in the review.

πŸ’‘Clipper

Clipper is an open-source 3D printer firmware that is user-friendly and customizable. The t500 runs on Clipper, which is significant because it allows for ease of use and the ability to make adjustments and updates to the printer's operation, as discussed in the video.

πŸ’‘Touch Pad

The touch pad on the t500 is a 7-inch interface that is similar to a Sonic PAD and runs on a quad-core Cortex A53 processor. It is used for interacting with the printer's software and initiating prints, serving as a central control unit for the machine.

πŸ’‘Extruder

An extruder is the component of a 3D printer that melts and pushes filament through the print head to create layers of an object. The t500 features a dual gear direct extruder, which is highlighted in the script for its ability to handle a variety of filament sizes and types.

πŸ’‘Print Speed

Print speed refers to the rate at which a 3D printer can create an object. The t500 is tested for printing at 180 millimeters per second, a speed that impacts the quality and efficiency of the printing process, as demonstrated in the video's various print tests.

πŸ’‘Voxel PLA

Voxel PLA is a brand of filament created by a print farm in Southern California, known for its high quality and reliability due to extensive testing. The video mentions Voxel PLA Pro, a modified version of PLA that supports high-speed printing, which is relevant to the t500's capabilities.

πŸ’‘Auto Bed Leveling

Auto bed leveling is a feature that allows a 3D printer to automatically adjust the print bed to ensure a flat and even surface for printing. The t500 performs auto bed leveling by probing 49 points on the bed, which is crucial for achieving high print quality, as shown in the setup process of the video.

πŸ’‘Quality Control

Quality control refers to the processes used to ensure that a product meets certain standards of quality. The video discusses some quality control issues found in the prototype t500, such as defective screw threads and a disconnected heat cartridge cable, which are important considerations for potential buyers.

Highlights

The Congo T500 is a 3D printer prototype with a large print volume of 500mm cube.

Comgrow, primarily known as a Creality reseller, is entering the 3D printer market with the T500.

The T500 features modular linear rails on the x, dual y, and dual z axes for enhanced stability.

The printer uses a 600-watt Meanwell power supply to heat the large bed effectively.

Clipper firmware is utilized, with a 7-inch touchscreen pad handling processing tasks.

A 32-bit motherboard connects stepper motors, limit switches, and the print head.

The T500 includes a six-and-a-half-to-one ratio dual gear direct extruder and comes with three hardened steel nozzles.

The printer is priced around $900, offering significant hardware features for the cost.

Voxel PLA sponsors the review, providing high-quality and affordable PLA Pro filament.

The T500 setup involves attaching the gantry to the base, reinforcing it with brackets, and connecting cables.

Auto-home, Z calibrate, Z tilt, and bed mesh functions ensure proper setup and leveling.

The printer achieves a print speed of 180 mm/s with reasonable print quality.

The print bed heats up within acceptable timeframes, with a slight temperature variance from center to edges.

The review identifies an issue with the print surface adhesion and recommends using glue to facilitate print removal.

The printer successfully handles various filament types, including PLA, PETG, TPU, and nylon carbon fiber, with some minor cooling issues noted.

The review concludes with a positive overall assessment, highlighting the T500's potential and value despite some quality control issues in the prototype.

Transcripts

play00:00

welcome back to Aurora Tech Channel

play00:02

today I will be reviewing a huge machine

play00:05

the Congo t500

play00:08

this is a final prototype from com girl

play00:10

and the retail version may have some

play00:12

minor changes but I will just base my

play00:14

review on my personal first-hand

play00:16

experience with the machine that I

play00:18

received

play00:19

many of you may not have heard of

play00:21

comgrow they are one of creality's

play00:23

resellers who have been selling

play00:24

thousands of creality printers on Amazon

play00:26

for many years

play00:28

previously I reviewed their laser

play00:30

engraver the Z1 and the mini desktop CNC

play00:34

the t500 is their first 3D printer and

play00:37

it's an interesting choice to start with

play00:38

something at this size but let's take a

play00:40

look at what you can get from the t500

play00:43

as the same suggests the printed volume

play00:45

of this large bed Slinger is a 500

play00:47

millimeter Cube which is bigger than

play00:49

anything I have reviewed before

play00:51

the total way of the machine is over 80

play00:53

pounds

play00:55

the motion system uses modular linear

play00:57

rails on the x dual Y and dual Z axes

play01:01

there are two brackets made of solid

play01:03

aluminum at the back to enhance the

play01:05

rigidity of the tall gantry

play01:07

the print surface is a spring steel

play01:09

sticker sheet and a meanwhile 600 watt

play01:11

PSU is used to heat up the huge bed

play01:15

the machine runs Clipper and it uses a 7

play01:18

inch touch pad that's pretty similar to

play01:20

a Sonic PAD as its touch screen

play01:23

the Linux OS and Clipper are actually

play01:25

installed on the pad

play01:27

the 32-bit motherboard is used to

play01:29

connect the stepper Motors limit

play01:30

switches and the print head while all

play01:33

the processing is handled by the 7-inch

play01:35

pad

play01:36

the hardware of the pad isn't specified

play01:38

on their product page but as it's from

play01:40

maker base I believe it's a megabase 7

play01:42

inch pad that runs on a quad core cortex

play01:45

a53 processor with one gigabyte RAM and

play01:48

8 gigabytes emmc which is pretty

play01:50

standard configuration for a Clipper pad

play01:52

there is a six and a half to one ratio

play01:54

dual gear direct extruder and although

play01:57

the heater block is a volcano style one

play01:58

it's using a non-volcano style nozzle

play02:02

it comes with three extra hardened steel

play02:04

nozzles sized at 0.4 0.6 and 0.8

play02:08

millimeters for other small details the

play02:11

belt tension can be adjusted using a hex

play02:13

wrench on every linear module and the

play02:15

filament roller is all metal with an

play02:17

adjustable screw to control the

play02:19

smoothness of the bearing inside

play02:21

with all these Hardware components this

play02:23

machine is priced at around 900 I would

play02:26

like to thank Conger for sending us this

play02:28

machine to review but before we get

play02:30

started I would also like to thank voxel

play02:32

pla for sponsoring today's video

play02:35

voxel pla is a brand created by a print

play02:38

Farm in Southern California where they

play02:41

exclusively use their own filament with

play02:43

over 150 3D printers that are operated

play02:46

24 7 non-stop this extensive testing

play02:50

leads to high quality and reliability in

play02:53

their filaments

play02:54

voxel pla Pro is a modified version of

play02:57

pla that provides higher impact strength

play03:00

and supports high-speed printing of up

play03:02

to 500 millimeters per second while

play03:04

maintaining a flow rate of up to 25

play03:07

millimeters Cube per second at a regular

play03:09

printing temperature of 210 degrees

play03:12

Celsius

play03:13

voxel pla Pro is also affordable at just

play03:16

16.99 for a one kilogram roll ordering

play03:20

three rolls comes with free shipping and

play03:23

bulk discounts are available starting

play03:25

from six rolls

play03:27

they have recently launched new filament

play03:29

colors as well as the vision enclosure

play03:31

kit that includes all the necessary

play03:33

parts to fully enclose your bamboo lab

play03:35

p1p for more information please visit

play03:38

voxelpla.com

play03:41

the machine comes with a large box that

play03:43

weighs almost 90 pounds

play03:45

all the parts are well protected by

play03:47

laser cut foam and even though the

play03:49

machine is huge the components are

play03:52

pretty simple

play03:53

it's a typical bed Slinger but

play03:55

everything is just bigger

play03:56

we have a fully assembled base with dual

play03:59

y-axis modular linear rails the Gantry

play04:02

with the Dual z-axis the x-axis and the

play04:05

print head

play04:06

there are also two brackets to reinforce

play04:08

the Gantry a 7 inch Clipper pad the

play04:11

screen Mount filament holder power cord

play04:14

a tool box user manual and a roll of

play04:18

sample filament

play04:19

like all other bad singers you just put

play04:22

the Gantry on the base

play04:23

the good thing is the screws were

play04:25

tightened from the top so you don't have

play04:27

to flip this heavy printer and tighten

play04:28

them from the bottom

play04:30

put the brackets at the back to

play04:32

reinforce the Gantry Mount the spool

play04:34

holder on top and not the screen bracket

play04:36

on the right side

play04:37

when I compare the screen to a regular

play04:39

4.3 inch touchscreen it looks huge but

play04:42

it doesn't seem all that big on this

play04:44

t500

play04:47

there's also ribbon cable with a cable

play04:49

chain so we just need to put it on top

play04:50

of the Gantry and connect some cables

play04:52

including the print head x-axis motor

play04:55

and limit switch the Dual C access

play04:57

Motors and two cables for the screen

play05:00

finally flip to your local voltage with

play05:03

the power supply at the back

play05:05

let's turn on the machine

play05:07

I'm happy to see this standard Clipper

play05:09

screen personally I prefer this more

play05:12

than any self-developed UI by different

play05:14

manufacturers

play05:15

I will start with auto home to make sure

play05:17

the stepper Motors limit switches and

play05:20

the inductive bet Leveling Sensor all

play05:22

working

play05:23

then go to the leveling menu Z calibrate

play05:26

means the offset and Clipper Z tilt

play05:29

means Gantry leveling and bed mesh Means

play05:31

Auto leveling

play05:33

I will start by setting the Z offset

play05:35

with a paper test

play05:36

as there is no leveling knob underneath

play05:38

the bed and we don't have to adjust the

play05:40

bed corners

play05:41

next I will let it level the gantry

play05:45

finally I will do a round of Auto bed

play05:47

leveling it's going to probe 49 points

play05:50

on the bed

play05:52

okay the setup is now done

play05:55

let's start with a simple benchy the USB

play05:58

drive comes with a skin Cura I would

play06:01

just add the Congo t500 and there are

play06:04

two of them I'm not sure which is which

play06:06

so I will just randomly pick one

play06:09

let's take a look at the print profile

play06:11

the default layer height is 0.2

play06:13

millimeters the print speed is set to

play06:15

180 millimeters per second the walls are

play06:18

being printed from 140 to 160

play06:20

millimeters per second the top and

play06:22

bottom are 100 the first layer is 40 and

play06:25

the acceleration is set to 3000 and 1000

play06:28

for the first layer

play06:29

let's take a look at the extruder the

play06:32

retraction distance is 0.5 and the speed

play06:35

is 40 millimeters per second

play06:37

so everything seems pretty reasonable

play06:40

let's slice a benchy the estimated time

play06:43

is 33 minutes I think there's no way

play06:45

that printing at 180 milbers per second

play06:47

will finish a bench in 33 minutes but

play06:50

let's connect the Moonraker plug-in and

play06:52

send the print job to the machine

play06:54

type in the machine's IP address check

play06:56

the ultimaker format thumbnail and we

play06:58

can upload it to the printer and start

play07:00

the print

play07:16

thank you

play07:23

let's do a sound test I place the meter

play07:26

a few inches away from the machine it

play07:28

stays in the low 60s in decibels and

play07:31

occasionally jumps to the mid 60s

play07:33

I will let it finish and then see the

play07:36

time and print quality

play07:39

the print finishes in 43 minutes which

play07:42

is 10 minutes longer than the estimated

play07:43

time and is more in line with my

play07:45

expectations from a 180 print speed

play07:48

the quality is pretty decent for a fast

play07:50

machine with good Cooling and just a bit

play07:53

of stringing

play07:54

however I had issues with removing the

play07:56

print from the bed and accidentally

play07:58

damaged it

play07:59

I talked to Congo about this and I will

play08:02

discuss this more later

play08:04

but for now I would just apply some glue

play08:06

to the bed to work as a release agent to

play08:08

continue my testing

play08:10

I will then print a number slider to

play08:12

test the clearance as you can see I've

play08:15

applied some glue to the bed to avoid

play08:17

causing further damage to the print

play08:18

surface

play08:19

[Music]

play08:27

foreign

play08:30

[Music]

play08:39

the print finishes in 3 hours and 17

play08:41

minutes which is almost an hour over the

play08:43

estimated time there is some stringing

play08:46

and using this clear color for the

play08:48

number slider the numbers are hard to

play08:50

see however the clearance is good so the

play08:53

slider is very smooth

play08:56

then I will test the retraction of the

play08:59

extruder by printing my honeycomb box

play09:00

which is Tiny patterns on all sides

play09:07

foreign

play09:10

[Music]

play09:22

[Music]

play09:33

than I would prefer but all of the

play09:36

patterns were printed successfully

play09:38

let's do a comparison to other New

play09:40

Generation machines it's not the best or

play09:43

the worst I would say it's a pretty

play09:45

average print compared to all other

play09:46

machines

play09:48

next I will print the robot alpaca from

play09:50

perusa and compare its print quality

play09:52

with other machines

play09:54

[Music]

play10:15

foreign

play10:17

[Music]

play10:23

[Music]

play10:34

it took 5 hours and 48 minutes which is

play10:37

way longer than the estimated time from

play10:39

the slicer let's do a comparison to

play10:41

other New Generation machines

play10:43

When comparing it to the ender3v3se

play10:46

which also printed this model at 180

play10:48

millimeters per second the print speeds

play10:50

are pretty much the same but the print

play10:52

quality on this t500 is better

play10:55

compared to the fastest machine that has

play10:57

printed this model so far which is that

play10:59

any cubic Cobra 2 the Cobra 2 offers

play11:02

better quality and print speed in

play11:05

comparison to the creality K1 the print

play11:07

quality is similar but the K1 is faster

play11:10

in comparison to the bamboo lab p1p the

play11:13

p1p provides better print quality and

play11:16

faster speed

play11:17

lastly when compared to the Anchor make

play11:19

m5c the print quality of the anchor make

play11:22

is slightly better but the t500 is

play11:25

faster

play11:26

I will then switch to a 0.8 millimeter

play11:29

nozzle to print a large lampshade

play11:31

the height of the lampshade reaches the

play11:32

machine's maximum at 500 millimeters

play11:36

since the maximum flow rate of this hot

play11:37

end is approximately 30 millimeters Cube

play11:40

per second when converted to a 0.8

play11:42

millimeter nozzle it reaches about 58

play11:44

and a half millimeters per second

play11:46

so I will set the print speed to 50

play11:49

millimeters per second and the first

play11:50

layer is now printing at 25 millimeters

play11:52

per second

play11:55

the print starts at 25 millimeters per

play11:57

second for the first layer and it has no

play12:00

issues

play12:01

once it starts to print the wall it

play12:03

speeds up to 50 millimeters per second

play12:05

which also looks fine

play12:07

however I can see some overhanging at

play12:10

the lower half of these squares having a

play12:12

minor cooling issue

play12:13

the top half of these squares print

play12:15

better than the lower half

play12:17

I will try to slow it down to 50 of the

play12:19

speed at 25 millimeters per second and

play12:22

see if there is any difference

play12:24

the clarity of the filament does look

play12:26

better when printing slower but it seems

play12:28

the top half is still better than the

play12:30

lower half and slowing it down doesn't

play12:32

make a huge difference

play12:34

anyways I do like the clarity when

play12:36

printing at a slower speed and it would

play12:38

also be better as a lampshade

play12:40

so I will just print at a slower speed

play12:43

and let it finish

play12:45

okay it appears that both the extruder

play12:48

and hot end can maintain a 50

play12:50

milliliters per second speed as I didn't

play12:52

see any under Extrusion issues on a

play12:54

print speed of either 25 or 50 movements

play12:57

per second

play12:59

but the bottom half of the squares still

play13:01

shows some minor cooling issues on the

play13:03

overhanging part

play13:04

the print took 12 and a half hours to

play13:06

finish which is way longer than the

play13:08

estimated time since I slowed it down to

play13:10

25 millimeters per second

play13:13

despite some cooling issues on the

play13:14

bottom half of the squares the lampshade

play13:16

still looks cool and I'm quite happy

play13:19

with this print

play13:22

then I will print a kitchen towel hanger

play13:24

using petg since the maximum temperature

play13:27

of this machine only reaches up to 80

play13:29

degrees Celsius

play13:31

[Music]

play13:44

[Music]

play13:46

okay

play13:49

[Music]

play13:55

people

play14:01

[Music]

play14:08

the print finished in one hour and 35

play14:10

minutes displaying typical petg

play14:12

characteristics with minimal stringing

play14:15

it is fully functional and I have no

play14:17

complaints

play14:19

next I will print a TPU wallet I will

play14:23

set the print speed to 50 millimeters

play14:24

per second for everything including the

play14:27

first layer and walls

play14:33

foreign

play14:34

[Music]

play14:40

[Music]

play14:47

[Music]

play14:57

this six and a half to one dual gear

play14:59

direct extruder also handled it very

play15:01

well and the Extrusion was perfect

play15:05

finally I will print with some nylon

play15:08

carbon fiber I had stored a few rolls of

play15:10

nylon and nylon combination filaments in

play15:13

the new sunloo S4 filament dryer in

play15:15

storage mode before using them I also

play15:18

heated them at 70 degrees Celsius for

play15:20

another hour to ensure that the pacf was

play15:22

in good condition

play15:23

[Music]

play15:43

thank you

play15:46

[Music]

play15:54

the result is very nice the layers look

play15:57

good and the print is fully functional

play15:59

so for nylon carbon fiber if the

play16:02

filament is dry enough you really don't

play16:04

need anything fancy

play16:06

any machine with a hardened steel nozzle

play16:08

at 260 to 270 degrees Celsius works just

play16:11

fine

play16:12

let's talk about the pros and cons of

play16:15

this printer starting with the pros

play16:17

one the motion system is excellent it

play16:21

uses module linear rails on the X do a y

play16:24

and dual Z axis making it almost as good

play16:26

as a 3000 snapmaker Artisan in terms of

play16:29

the motion system

play16:31

two the frame is super rigid there are

play16:34

no issues even with this huge 500 by 500

play16:37

print bed swinging back and forth and

play16:39

the 500 millimeter tall guarantee is

play16:41

also sturdy

play16:43

three the z-axis is supported by dual Z

play16:46

modules with two independent stepper

play16:49

drivers so Clipper can use the inductive

play16:51

fat Leveling Sensor to level the gantry

play16:53

there are two manual knobs at the top

play16:55

when the machine is off you can still

play16:58

manually move the Gantry up and down for

play17:00

nozzle changing or other maintenance

play17:02

4. the print speed is fairly Fast

play17:05

Printing at 180 millimeters per second

play17:07

with a 3 000 millimeters per second

play17:09

squared acceleration at a 0.2 millimeter

play17:12

layer height

play17:13

printing a standard quality 0.2

play17:15

millimeter layer height Banshee in 43

play17:17

minutes is reasonable considering this

play17:19

large bed Slinger can't move as fast as

play17:21

a small printer

play17:22

five the print quality is decent it

play17:26

passes all the tests including clearance

play17:28

and retraction

play17:29

for decorative prints like the robo

play17:31

alpaca the result is in line with other

play17:33

latest generation machines

play17:36

six

play17:37

the firmware uses open source Clipper

play17:39

and the screen is a standard Clipper

play17:40

screen

play17:41

you can have SSH and root access using

play17:44

the default makerbase Pi login and

play17:45

password

play17:47

for the web interface it also uses

play17:49

standard fluid

play17:50

this decision is actually smarter than

play17:52

what some other manufacturers choose by

play17:55

trying to modify Clipper firmware or

play17:57

create their own touchscreen UI and

play17:59

framing it as their own self-developed

play18:01

system this often ends up with buggy

play18:03

firmware a bad UI and it overall ruins

play18:06

the user experience

play18:08

7. the print bed is big but it can still

play18:11

heat up within a reasonable time frame

play18:13

the machine comes with a 600 watt

play18:15

meanwhile power supply

play18:17

heating from room temperature of about

play18:19

25 degrees Celsius to 50 degrees Celsius

play18:21

requires around four and a half minutes

play18:23

heating to 60 degrees Celsius requires 7

play18:26

Minutes 70 degrees Celsius requires 10

play18:28

minutes and 80 degrees Celsius requires

play18:30

16 minutes

play18:32

the temperature difference from the

play18:33

center to the edges is around 7 to 13

play18:35

degrees which is acceptable for a bed of

play18:38

this size

play18:39

8. the filament holder has a bearing and

play18:42

a screw for adjusting smoothness it can

play18:44

feed the filament smoothly without

play18:46

causing it to roll back and create

play18:48

filament tangles

play18:49

now for the cons one the main issue I've

play18:54

encountered with this printer is related

play18:55

to the print surface it sticks too well

play18:58

to PLA and the adhesive used to attach

play19:00

the print surface of the steel sheet is

play19:02

pretty weak as a result the print

play19:05

surface attaches from the steel sheet

play19:07

and tears or peels off when a print is

play19:09

being removed however after glue is

play19:11

applied the printer works perfectly fine

play19:14

two the nozzle's maximum temperature is

play19:17

300 degrees Celsius but the maximum bed

play19:20

temperature is 80 degrees Celsius you

play19:22

won't be able to print ABS ASA or

play19:25

polycarbonate as these materials

play19:27

typically require a heated by

play19:28

temperature of 100 degrees Celsius or

play19:30

higher

play19:32

three the cooling is sufficient when

play19:34

printing with a 0.4 millimeter nozzle

play19:36

but when using a 0.8 millimeter nozzle

play19:38

the extruder is pushing out much more

play19:40

filament

play19:41

printing at 50 Motors per second with a

play19:43

0.88 millimeter line width and a 0.64

play19:46

millimeter layer height results in a

play19:48

flow rate of close to the hot end limit

play19:50

of 30 millimeters Q per second both the

play19:52

hotend and extruder can keep up but the

play19:55

overhanging on the bottom half of the

play19:56

square is not as good as the top half

play19:59

this is mainly due to insufficient

play20:00

Cooling and this was confirmed when I

play20:02

slowed down the print to 50 of the

play20:04

original speed and still saw no

play20:06

improvement

play20:08

4. the location of the filament sensor

play20:11

could be improved it would be better if

play20:13

it were integrated into the print head

play20:14

currently it's positioned one to two

play20:17

inches above the print head which can be

play20:19

kind of obstructive when feeding in

play20:20

filament

play20:21

5. the input shaper was pre-calibrated

play20:24

in the factory and I didn't recalibrate

play20:27

it as my FL Sun V 400 machine has also

play20:30

been using pre-calibrated values for a

play20:32

year and hasn't encountered any issues

play20:34

it seems that this t500 is a similar

play20:37

case but when you need to attach an

play20:39

accelerometer you still need to use

play20:41

screws and attach it to the print head

play20:43

using can bus with one single cable and

play20:46

integrating the accelerometer into print

play20:47

head like many other New Generation

play20:49

machines would be a better option

play20:52

six

play20:54

since the machine I received is still a

play20:55

prototype there are some quality control

play20:57

issues for example two of the screw

play21:01

threads were defective and the heat

play21:03

cartridge cable was disconnected when

play21:04

the machine arrived so at first the

play21:07

nozzle couldn't heat up

play21:08

when I open the printhead cover for

play21:10

inspection I found that the heat

play21:12

cartridge cable had come loose even

play21:13

though hot glue had been applied

play21:15

this issue was mainly caused by the

play21:17

cable being too short and the zip tie

play21:19

being too tight causing it to pull on

play21:21

the cable and detach the connector

play21:23

in conclusion the harbor of this printer

play21:26

is solid it uses modular linear rails on

play21:28

all axes and it's very uncommon to see

play21:31

this kind of motion system on a 3D

play21:32

printer

play21:33

I've only encountered a similar motion

play21:35

system on another three thousand dollar

play21:37

Machinery reviewed the snapmaker Artisan

play21:40

while the small details on the snapmaker

play21:42

are better the actual cost of living

play21:44

your modules for both machines are

play21:46

similar

play21:47

considering that the t500 is priced at

play21:49

around 900 with this motion system seven

play21:52

inch Clipper pad and 600 watt meanwhile

play21:55

power supply the hardware itself is well

play21:57

worth the price the print speed and

play22:00

print quality are satisfactory and the

play22:02

print volume is enormous so I would say

play22:05

this machine has a lot of potential and

play22:07

the overall value is also pretty good

play22:10

quality issues I saw were reported to

play22:12

comgrow and they assured me that they

play22:14

have addressed them and will conduct

play22:16

detailed inspections during large scale

play22:18

production regarding the print surface

play22:20

they explained that the one on my

play22:22

testing machine was manually glued and

play22:23

attached but for large scale production

play22:25

all of them will be processed by

play22:27

machines producing more consistent

play22:29

results

play22:30

as I haven't had the chance to evaluate

play22:32

a final large batch production version

play22:34

of the t500 I can't confidently place

play22:37

this machine on my recommendation list

play22:38

just yet

play22:40

currently only seven out of 100 machines

play22:42

I've tested have made it to my list of

play22:44

recommendations on auroratechannel.com

play22:47

if I find that their large batch

play22:49

production has addressed all the quality

play22:50

issues I will definitely consider adding

play22:52

it to my list in any case I've put a

play22:55

link to the Concord t500 in the video

play22:57

description

play22:58

that's it for today's video if you found

play23:01

it useful please hit the like button and

play23:03

consider subscribing to our Channel

play23:04

thank you for watching and I will see

play23:06

you next time

Rate This
β˜…
β˜…
β˜…
β˜…
β˜…

5.0 / 5 (0 votes)

Related Tags
3D PrintingCongo t500ComgrowPrinter ReviewLarge BedModular DesignHigh SpeedPrint QualityFirmwarePrototype Test
