TLDRIn week 8 module 2 of the ECDIS training, Second Mate Evaristo Feliciano instructs on the operational use of electronic chart display systems. The focus is on activating display categories, information layers, and monitoring safety features. The session covers the basic functions of ECDIS, particularly in route planning. It explains how to navigate the display layers, including base, standard, and custom, and how to adjust settings for objects, soundings, and additional information. The training also touches on handling ENC format charts, route editing, and the use of tools like the scale bar and grid lines. The session concludes with an overview of the learning outcomes and an introduction to upcoming quizzes and recitations.
Takeaways
- π The training is focused on the operational use of Electronic Chart Display and Information Systems (ECDIS), specifically on navigation and route planning.
- π ECDIS has three display categories: base, standard, and custom, which can be accessed through the chart menu in the task list display panel.
- π The standard display is primarily used for navigation as it reduces potential distractions by limiting the objects shown on the chart.
- π The custom display allows for the inclusion of additional information layers, which can be activated based on user needs.
- π§ Safety features such as isolated dangers and depth settings can be adjusted to ensure safe navigation.
- π Display options for various chart layers like depth contours, cable pipelines, and names can be toggled on or off to customize the view.
- π The scale bar and grid lines are important tools for navigation and can be displayed on the screen for reference.
- π ENC (Electronic Navigational Chart) format charts can be handled within ECDIS, allowing for the adjustment of chart information layers.
- π The root editor is a key tool for loading, editing, and unloading routes, with functionalities to focus on specific routes and adjust waypoints.
- π The training concludes with a quiz and recitation to reinforce learning, emphasizing the importance of understanding and applying the discussed topics in practical scenarios.
Q & A
What are the three display categories in ECDIS as mentioned in the script?
-The three display categories in ECDIS are the display base, standard display, and all layer category display.
How do you access the chart menu to select display categories in ECDIS?
-You access the chart menu by opening the task list menu on the control panel, and then selecting the chart from the appropriate line of the task list.
What is the purpose of the standard display category in ECDIS?
-The standard display category in ECDIS is used to reduce objects on the chart that might distract the user, focusing on essential navigational information.
How can you control the display of individual chart information classes in ECDIS?
-You can control the display of individual chart information classes by using the layer control, which is found in the chart panel under the layers section.
What does the 'custom' display category in ECDIS allow you to do?
-The 'custom' display category in ECDIS allows you to turn on the presentation of objects including additional information display at the user's discretion.
Why is it important to set the 'isolated danger' in ECDIS?
-Setting the 'isolated danger' in ECDIS is important to turn on the display of isolated dangers with depths over them larger than the safety depth, enhancing safety during navigation.
What is the function of the scale bar in ECDIS?
-The scale bar in ECDIS is used to display the chart scale graphic presentation, typically found on the left-hand part of the screen.
How do you handle NC format charts in ECDIS as described in the script?
-To handle NC format charts in ECDIS, you open the chart panel, switch to the ENC page, and adjust the settings for ENC format charts, such as checking and unchecking various objects and layers.
What is the role of the 'root editor' in ECDIS as discussed in the script?
-The 'root editor' in ECDIS is used for loading, editing, and unloading routes. It allows users to modify waypoints, create new waypoints, and adjust the route plan.
How can you monitor a route in ECDIS according to the script?
-To monitor a route in ECDIS, you load the desired route using the root editor, then activate the route by pressing the 'active root monitoring' button, which will load the route for navigation.
What is the significance of the 'focus on root' function in ECDIS?
-The 'focus on root' function in ECDIS allows users to display the selected route plan on the chart, providing an overview from departure to arrival points.
Outlines
π Introduction to ECDIS Display Categories and Safety Features
The instructor, Second Mate Evaristo Feliciano, begins the session by introducing the learning outcomes for week 8 module 2 of the ECDIS (Electronic Chart Display and Information System) course. The focus is on activating display categories and information layers, as well as monitoring safety features. The instructor explains the basic functions of ECDIS, particularly in route planning. He outlines the three display categories in ECDIS: base, standard, and all layers. These categories are accessed through the chart menu in the task list display panel. The base display is the first layer of the chart, standard reduces objects that might cause distraction, and custom allows for additional information display. The instructor also discusses the display of various chart objects, such as spot soundings, cable pipelines, and other information layers. The importance of setting the correct display for isolated dangers and depth contours is emphasized.
π Exploring ENC Charts and Customizing Display Settings
The second paragraph delves into handling NC format charts, specifically ENC (Electronic Navigational Chart) charts. The instructor demonstrates how to open the chart panel and navigate to the ENC page to adjust display settings for ENC format charts. He explains how to show or hide all objects and how to select specific objects to display. The paragraph also covers the customization of display settings such as scale, minimum scale, and the selection of display styles like simplified or paper chart. The instructor discusses the activation of objects in an ENC chart and the use of the root editor for route planning. He guides through the process of loading and unloading routes, focusing on a route for display, and activating route monitoring. The paragraph concludes with a brief mention of the upcoming lab demonstration where participants will see these objects highlighted or selected.
β΅οΈ Route Editing and Management in ECDIS
In the third paragraph, the focus shifts to the practical aspects of route editing and management within the ECDIS system. The instructor explains how to load a route into the root editor and how to focus on a specific route for navigation. He demonstrates the process of loading multiple routes simultaneously and how to select which route to display. The instructor also shows how to unload routes that are not needed. He then moves on to the waypoint editor, explaining how to edit existing waypoints and how to add new ones along a route. The process involves using the mouse to position the cursor on the map, adjusting the waypoint's position, and saving the changes. The paragraph concludes with a reminder that these procedures will be demonstrated in the lab and that participants will have a quiz and recitation to complete.
π Course Summary and Assessment Details
The final paragraph summarizes the course content and outlines the assessment activities for the participants. The instructor reminds the students that the topics discussed are applicable to their teaching and learning activities. He mentions that there will be a quiz, recitation, and assignment based on the lecture material. The quiz will test the students' knowledge of the topics covered, while the recitation will require them to write about the discussed topics and provide answers to questions. The instructor concludes by informing the students about the upcoming midterm and assignment, wishing them a good day.
Mindmap
Keywords
π‘ECDIS
π‘Display Categories
π‘Information Layers
π‘Safety Features
π‘ENC
π‘Standard Display
π‘Custom Display
π‘Root Planning
π‘Waypoint Editor
π‘Active Route Monitoring
Highlights
Introduction to week 8 module 2 of Navigation 6 focusing on the operational use of electronic chart display systems (ECDIS).
Learning outcomes include activating display categories, information layers, and monitoring safety features in ECDIS.
Explanation of basic standard functions of ECDIS, particularly in route planning.
ECDIS has three display categories: base, standard, and all layers, which are selected from the chart menu.
Demonstration of how to open the task list menu and chart panel to select display layers.
Description of the display categories and their functions in presenting different types of chart objects.
The standard display is used to reduce objects on the chart that may cause distraction.
Custom display allows for the inclusion of additional information layers for navigation.
Spot soundings and their importance in navigation safety, with settings to display depths over isolated dangers.
Instructions on how to display cable and pipeline names for better chart information.
Options to display other information such as depth contours and turning on/off chart layers.
Activation of the scale bar and grid lines for better chart navigation and orientation.
Enabling the display of chart boundaries to understand the extent of the map.
Demonstration of how to set the display category to standard, base, or custom.
Handling NC format charts and setting up ENC format charts for better navigation.
Explanation of how to load and unload routes in the route editor for navigation planning.
Guidance on how to edit waypoints and adjust route plans using the waypoint editor.
Information on the upcoming quiz and recitation, emphasizing the importance of understanding discussed topics.
Conclusion of the session with a reminder about the midterm and assignment, encouraging good learning practices.
Transcripts
All right good day gentlemen we are now
on week 8 module 2 of our Nab stick
Navigation 6 operational use of
electronic chart display again I am your
instructor second mate evaristo
Feliciano our learning outcomes is to
activate display categories and
information layers and monitoring safety
features also to demonstrate the basic
standard function of e this basic
operation especially in root
planning All right
so we go now to the
presentation of the data and also the
standard safety function of ecdis the
display
layers so ecdis has three display
category as we have discussed in our
last meeting or
session These are the display base
standard display and all layer category
display so on trans eis these categories
are selected from the chart menu part of
the task list display panel So You just
open
the task list Uh
menu on the control panel and the chart
panel
will appear you just select the
chart on the appropriate line of the
task list so like this
one and this will open up the chart
panel
and you have to switch to the
layers Okay this will open and you have
to switch to the layers select the
layers So this page is intended to
control the display of individual chart
information classes by using the
following control Okay on the layer so
ibibigay niya yung mga display ng mga
object ng mga mapa ng mapa natin by
selecting the appropriate layers
Okay all right so meron tayong display
category we can switch to different
presentation of this display type base
turn on presentation of object included
the base display standard to turn on
presentation of object included in the
standard display and of course the
custom to turn on presentation of
objects including the additional
information display at the user
disc So yun Iyung
custom okay ang ginagamit sa Navigation
basically standard it reduces sa objects
on the chart yung pwede baka ma-distract
tayo So yung usually ginagamit natin but
if we need other information we go to
custom Okay so standard custom lang
talaga ang
ginagamit natin yung base that is only
there as the first layer of the chart
Tapos papatong na si standard papatong
na iung custom and of course yung all
lahat na ng object loed in the
additional information i-activate ni So
this are the Spot soundings This is also
very
important and if the setting is zero
all soundings are displayed so specify
mo kung anong sounding yan isolated
danger turn on display of isolated
danger with depths over them Larger Than
the safety
dep Okay then we have the cable
pipelines
names mga
pangalan Okay
so It will be also display other
information to turn on the display of
other information depth contour seed bo
name show all to turn all on the display
of the for mention chart layers to
display all hide all it will hide the
information chart layer so iha-hire niya
okay scale bar Turn on the display of
chart scale graphic presentation Nandyan
yan sa left hand part of the screen yung
scale bar Okay Grid lines turn display
of the coordinate Grid if you want to
display it pwede namang
hindi chart boundaries to turn on the
display of shift folio chart boundary so
makita mo yung mapa mo hanggang saan
lang yan of course na Tex Turn on the
display of navtex message symbol So para
malaman mo kung merong navtex
message Dian sa lugar na yan if you have
enough text
message All right
then This is where you set the category
standard base standard custom and select
custom for
example and this are the custom so
activated muna Okay balik lang tayo kti
activated and then Makikita mo mo yung
mga object na yan and then if you want
to close it kasi yun muna yung ah
default niya then you you turn It Off
click click click lang yan mag-off na
yan kung ano lang yung kailangan mo yan
yung palitawin mo lang show all lalabas
yan hide all itatago
ni Okay
so All right so Tingan natin Okay let's
continue so handling NC format chart
Okay open chart panel at least balik uli
tayo doon sa chart chart
panel Okay switching chart information
na
layer Okay we go to the enc page Okay
dito sa enc Uh page It
will open another information on the
enc other layer so we can set up this
page adjustment on enc format chart para
it sa mga mapa na
enc okay Again the same You can check
and check show all hide all Kung gusto
mo and then kung tanggalin mo lang kung
ano yung ayaw mo So These are the
objects that you can use or display and
then yung area areas
ah may drop down list yan then you can
select plane or
symbolize Okay plane lang siya yung mga
guhit niya hindi walang symbol so plain
lang yung points niya
pwedeng
simplified style or paper chart kung ano
yung nakikita mo sa paper chart yun ang
idi-display niya na na mga object
na kagaya sa paper chart So this is the
selection according to the user
Okay so for me I prefer symbolize and
paper chart
Okay so let's go to the next so these
are those you can set the
anc okay yamin that is very popular isin
scale minimum so you can Turn on the
display of an object on
inadmissible scale to it okay so yan
yung
Uh it minimize the display of the object
that is not necessarily in in a
particular scale so para hindi siya
congested All right so These are the
objects that we can activate in an enc
chart All right ito yyung m quality This
is the Cats Cats
Okay so It's up to you so It will be
demonstrated in the Lab how so you can
see those object when highlighted or
selected
Okay so again we go to root
editor Okay so hindi na chart panel ang
bubuksan natin ay root editor we go now
to root loading and unloading okay when
we open the root editor a root pel root
editor panel will appear ito yan and
then we can load the
root Press the load rot button here and
then select rot let's say St pittsburg
Hamburg Okay When you click that okay
the root of that
the name of that rot all the root will
appear Okay the root plan for that Uh Uh
rot will appear Okay let's see Okay so
It's here it's already loaded and this
are the waypoint starting from way point
zero all the way to its
destination Okay so if we want to see
this on the chart okay we can
Uh we can Uh select focus on
root so several roots can be loaded
simultaneously So pwede kang mag-load
uli then Lalabas lang dito iyung mga
pangalan and then you select What rot
you want okay to be
displayed Okay so ito iyung mga gawa
na now you want to see Press the focus
on root it yan then you will see the rot
okay
now to quick load the Ness rot for
monitoring agag Gusto mong makita
ma-monitor
siya Okay you load the you when you load
you press also the active root
monitoring ito iyan active rot monitor
So it will load the root for Navigation
na yan pero kung edit mo lang Huwag mong
pindutin yan Okay ito ung multiple oh na
root L So kung ano ung gusto mong tignan
diyan o gamitin yun ang lalabas so
selected sa ating example sa Peter
h Okay so pinili natin Iyung ah load rot
St Peter's Uh Okay ah St Peter's Hamburg
then we can also load ah shanghai
Hamburg Okay St pittsburg to Hamburg
shanghai Hamburg okay
so we can also unload so unload rote ito
yan then tatanggalin mo na press mo yung
ayaw mo then it will be
unloaded
Okay so in root editor panel You can
also load the necessary root and then
iung focus on root lalabas na iyung root
root plan nito sa mapa so dito na
lalabas So ano ang pipindutin Focus
on root okay lalabas na yan Okay ito
makikita na lahat yung yung overview
nung destination mo from departure to
arrival lalabas na yan
ayan
Okay kung gusto mong i-edit yung root
Pwede rin punta ka uli sa root
editor on the task list sa control panel
on the right side labas yan Okay ito na
yung kanina yung setting ng layers dito
yan sa chart ngayon yung root planning
editing ng root dito iyan sa root
editor Okay
so tingnan
natin root
editor sinel mo Iyung root editor
lalabas Iyung root editor panel so ito
Iyung root editor panel natin Okay ah
maglo-load root ka syempre St pittsburg
to Hamburg Ayan St
pittsburg
petersburg to Hamburg Okay yan yung root
L i-load natin Ayon kung gusto mong
i-edit yan Okay you press the waypoint
editor here ito yung pipindutin mo
ma-edit mo na yan okay pag pinindot mo
yan anong
lalabas okay lalabas sa sa mapa mo sa
gilid yung editor ito yung location ng
cursor yung Mouse git itong ginagalaw ko
yan ang location niya pagdating sa mapa
lalabas latitude longitude Okay para
ma-edit natin Okay Anong makikita natin
sa mapa ito nasa tagiliran lang to Ito
yung makikita
natin Okay so lalabas yan sa mapa yung
cursor mo lalabas may coordinates kanina
ito yung coordinates na lalabas Ayan
yung coordinates ng mapa ah sa mapa ng
ng cursor natin o yung pinagagalaw mo na
Mouse
Ayan and then ah you can position That
um on the waypoint to be edited an ba
gusto mo itong i-adjust ito itapat mo
lang yung Mouse mo diyan left click mo
sasama na yan SAO then adjust mo
lang and then left click mo release Gan
lang siya okay dadalhin mo siya sa
waypoint left click edit mo pagalawin mo
and then left click Yun na yon kung saan
mo yung huling ni- left click yun ang
kanyang
position okay ngayon kung gusto mo ng
new waypoint you can click anywhere
along the leg ito Iyung Iyung course
line and then Halimbawa gusto mo rito
okay i- left click mo magkakaroon
ng ng symbol diyan
coordinates Okay then I pwede mo n
i-drag
yon okay i-click mo ayan then i-click mo
uli sasama SAO i-adjust mo left click
release Okay ganon lang Ian so It will
be demonstrated on your Uh lab ah
gentleman Okay then after that ah
satisfied ka na you save it
o on the root editing panel ito yan then
save mo and then unload mo m na ung rot
kung hindi mo gagamitin ito yung
pang-load alr so h diyan lang muna tayo
guys and after this you will have your
quiz also meron din kayong recitation ah
kung ano yung na-discuss ko na mga
topics dito isulat niyo lang and then
ah not necessarily the procedure yung
mga topics lang na na-discuss ko at yun
ang turn in nio guys
Okay so applicable sa ating ang ating
teaching and learning activities ay
applicable sa atin Iyung number one and
number two Iyung number three sa love
iyon Iyung
exercise so lecture natin meron tayong
quiz
recitation okay question and answer yun
Meron akong binigay sa inyo And you
provide the answer of course then quiz
and or assignment So So ngayon
a second we tayo ng midterm so alternate
nakaraan assignment now we have
a So you will
have
next So that's it gentlem and have a
good
day
5.0 / 5 (0 votes)
