8-bit computer RAM intro

Ben Eater
31 Jul 201613:45

Summary

TLDRThis video script delves into the construction of a 16-byte memory system using 8-bit registers, each with a write and enable signal. It explains the concept of static and dynamic RAM, highlighting the differences in complexity and speed. The script introduces the 74 LS189 chip, a 64-bit RAM chip, and outlines its use in building an 8-bit, 16-byte memory system. It also discusses the necessity of inverting the chip's output due to its inverse logic and the importance of address decoding for memory access.

Takeaways

  • 😀 The video discusses the construction of a bit register with a single input and output, which can store one bit of data.
  • 🔧 The interface for the bit register includes an input, an output, a write signal, an enable signal, and a clock signal.
  • ⏱️ The clock signal is crucial for making the register synchronous, ensuring data is only read on the rising edge of the clock.
  • 📈 The video then scales up to an 8-bit register, which operates on the same principles but can store eight bits of data at once.
  • 💾 To build computer memory, the concept is extended to create an 8-bit storage unit replicated multiple times to store multiple bytes.
  • 🔑 Each memory location has a separate write and enable signal, allowing individual control over each storage unit.
  • 🔄 The video introduces the concept of Dynamic RAM (DRAM) and Static RAM (SRAM), explaining their differences in refresh mechanisms and use cases.
  • 🛠️ The 74LS189 chip is introduced as a convenient way to build memory, being a 64-bit random access memory chip that can be used to create the desired 16-byte memory.
  • 🔢 The chip uses a 4-bit address to select which of the 16 memory locations is being accessed, simplifying the control mechanism.
  • ⚙️ The video concludes with a discussion of the pinout and functionality of the 74LS189 chip, including its use of inverse logic for outputs and the need for inverter chips.

Q & A

  • What is the primary function of a bit register?

    -A bit register is used to store one bit of data. It has a single input and a single output, with an LED indicating the stored bit. The interface includes an input, an output, a write signal, and an enable signal.

  • How does the write signal affect the bit register?

    -The write signal, when active, allows the bit register to store whatever is coming into the input.

  • What is the role of the enable signal in the bit register?

    -The enable signal, when active, sends the bit stored in the register to the output.

  • Why is the clock signal important for a synchronous register?

    -The clock signal is important because it synchronizes data storage with the rising edge of the clock, ensuring that data is only read or written at specific times.

  • How does an 8-bit register differ from a 1-bit register?

    -An 8-bit register stores eight bits of data instead of one, but it operates on the same principle with enable and write signals. The difference is that it has eight inputs and eight outputs, all managed through a bus.

  • What is the purpose of building a 16-byte memory?

    -A 16-byte memory is built by replicating the 8-bit storage units 16 times, allowing the storage of 16 bytes of data. Each byte has its own write and enable signals.

  • What is the difference between Dynamic RAM and Static RAM?

    -Dynamic RAM requires constant refreshing to maintain data because it uses a capacitor that discharges over time. Static RAM, on the other hand, does not need refreshing as it typically uses flip-flop circuits that retain data as long as power is supplied.

  • Why is Static RAM more expensive than Dynamic RAM?

    -Static RAM is more expensive because it uses more transistors and has more complexity in each memory cell compared to Dynamic RAM.

  • How does address decoding logic help in memory management?

    -Address decoding logic allows the selection of specific memory locations using an address. It uses AND gates and the address signals to enable the appropriate memory location for reading or writing.

  • What is the 74LS189 chip and how does it relate to the memory discussed in the script?

    -The 74LS189 is a 64-bit random access memory chip. It is used to build an 8-bit, 16-byte memory by using two of these chips, as each chip provides half the required memory width.

  • Why are inverters needed when using the 74LS189 chip?

    -The 74LS189 outputs the inverse of the stored value. Inverters are needed to re-invert these outputs to match the stored values.
