Macam macam gambar dalam konstruksi bangunan
Summary
TLDRThe video script discusses the fundamentals of construction drawings, emphasizing the importance of various types of architectural plans in building construction. It explains the significance of layout and elevation drawings, using an example of a 'denah tipe 60/150' to illustrate the building's area in relation to the land size. The script further delves into the details of construction elements such as foundation plans, cross-sections, and 3D visualizations, aiming to clarify the building's design for both professionals and laymen. It concludes by encouraging viewers to revisit the material for a deeper understanding of construction concepts.
Takeaways
- 🏠 The script discusses the basics of construction, focusing on the types of drawings required for building construction, which serve as references or guidelines during the construction process.
- 📐 The main drawings mentioned are the layout (denah) and the elevations (tampak), which are crucial for understanding the overall design and appearance of a building.
- 🔍 The term 'denah tipe 60/150' refers to a building with an area of 60 square meters on a plot of land with an area of 150 square meters.
- 📏 The script explains that the building area is usually smaller than the land area due to elements like garages and gardens that are not built upon.
- 🏢 In Jakarta, due to high land prices and scarcity, buildings are often maximized to use the available land, which can affect the design and layout.
- 🛏️ The script gives an example of a building layout with 2.5 bedrooms, explaining how the total area is calculated to be approximately 60 square meters.
- 📊 The drawings are typically made to a scale of 1:100, which helps in visualizing the actual size of the building components.
- 📈 The script distinguishes between different types of views such as front, side, and back elevations, emphasizing their importance in showing different aspects of the building.
- 🔩 It also introduces the concept of 'cross-sections' (potongan), which are drawings that show the internal structure of the building, and 'details' (detail), which focus on specific construction elements like foundations.
- 🏗️ The importance of understanding the construction details such as the foundation type, materials used, and their proportions is highlighted.
- 📈 The script mentions the use of 3D drawings to help visualize the building from a three-dimensional perspective, which is especially useful for people who may not fully understand 2D plans.
Q & A
What is the main topic of the video script?
-The main topic of the video script is the basic principles of construction, specifically focusing on the types of drawings required for building construction.
What are the two primary types of drawings mentioned in the script?
-The two primary types of drawings mentioned are the floor plan (denah) and the elevation (tampak).
What does the term 'denah tipe 60/150' refer to in the context of the script?
-The term 'denah tipe 60/150' refers to a building plan where '60' is the area of the building and '150' is the area of the land it is built on.
Why is the area of the building usually smaller than the area of the land?
-The area of the building is usually smaller than the land because there are often additional spaces like garages and gardens that are not built upon.
What is the standard scale used for drawing floor plans as mentioned in the script?
-The standard scale used for drawing floor plans is 1:100, meaning 1 unit on the drawing represents 100 units in reality.
What is the purpose of a 'gambar potongan' or section drawing?
-A 'gambar potongan' or section drawing is used to show the internal structure of the building, allowing viewers to understand the layout and details that are not visible in the floor plan or elevation.
What is the significance of the term 'pondasi' in the script?
-The term 'pondasi' refers to the foundation of a building, which is a critical part of construction that supports the structure and ensures its stability.
What is the difference between 'dinding bata' and 'trasram' mentioned in the script?
-Dinding bata refers to brick walls, while trasram is a waterproofing layer, typically made of a mix of cement and sand, applied below the brick walls to prevent water seepage.
Why are 3D drawings important in construction?
-3D drawings are important because they provide a more comprehensive and understandable view of the building from all angles, which can be particularly helpful for non-experts to visualize the final structure.
What is the purpose of the script's mention of 'gambar detail' or detail drawings?
-Gambar detail or detail drawings are used to show specific parts of the construction in greater detail, such as the foundation, columns, and other structural elements, to provide a clear guide for construction.
How does the script suggest one should study the material presented?
-The script suggests that the material should be studied thoroughly and reviewed multiple times, possibly through video tutorials on YouTube, to ensure a deep understanding of the concepts.
Outlines
🏗️ Basic Construction Drawings and Plans
This paragraph introduces the fundamental concepts of construction drawings, emphasizing the importance of various types of images required for building construction. It explains that these images serve as guidelines or references during the construction process. The speaker discusses the significance of the floor plan and elevation as the primary images, using an example of a housing brochure to illustrate the point. The explanation includes the meaning of 'design type 60/150,' which refers to the building's area being 60 square meters and the land area being 150 square meters. The speaker also touches on the scale used in architectural drawings, typically 1:100, and how measurements are represented in centimeters or millimeters.
📐 Understanding Building Sections and Details
The second paragraph delves into the specifics of construction drawings, including the meaning of a 'plan view' which is a top-down view of a building, and a 'section view' which is a vertical cut through the building at 1.5 meters high. The explanation includes details about walls, such as brick walls and concrete walls, and the distinction between them. The paragraph also covers 'elevation views,' which can include front, side, and back views of a building, highlighting the differences between them. Additionally, the concept of 'section drawings' is introduced, which are used to show the internal structure of a building, and 'detail drawings,' which focus on specific parts of the construction, such as foundation details.
🛠️ Construction Materials and 3D Visualization
In the final paragraph, the speaker discusses the use of materials in construction, such as the mix ratios for concrete and the use of different materials like sand and cement in foundations and walls. The paragraph explains the importance of waterproofing in construction and the use of 'trasram,' a mixture used for its water-resistant properties. The speaker also introduces the concept of 3D drawings as a tool for visualizing the construction in three dimensions, which is particularly useful for people who may not fully understand the building's appearance from plan and elevation views alone. The paragraph concludes with an encouragement to review the material and a sign-off in the style of a video script.
Mindmap
Keywords
💡Construction
💡Floor Plan
💡Elevation
💡Scale
💡Cross Section
💡Foundation
💡Detail Drawing
💡3D Model
💡Unit of Measurement
💡Architectural Drawing
💡Building Regulations
Highlights
Introduction to basic construction drawings required for building construction.
Explanation of the importance of drawings as a reference in construction projects.
Different types of drawings needed for construction, such as layout and elevation.
The significance of the floor plan and elevation in understanding the design of a building.
Description of 'denah tipe 60/150' indicating the building's area and land area.
Example of calculating the total land area and building area with given dimensions.
Difference between the land area and the building area, including common features like garages and gardens.
The prevalence of compact buildings in Jakarta due to expensive land prices.
Explanation of the unit of measurement used in construction drawings, such as M2.
Details on the scale used in construction drawings, typically 1:100.
Clarification on the use of different units like centimeters and meters in construction drawings.
The concept of a 'denah' as a top view of the building with a 1.5-meter height cut.
Different types of views such as front, side, and back views in construction drawings.
The purpose of 'gambar potongan' or sectional drawings to show the interior of the building.
Details on how to draw a sectional view to understand the internal structure.
Importance of 'gambar detail' or detail drawings for specific parts of construction like foundations.
Explanation of foundation types, materials, and their construction methods.
The role of 3D drawings in helping the public understand the building's appearance.
Encouragement for learners to review the material for better understanding.
Closing remarks with a reminder to study the material well and blessings.
Transcripts
Oh ya salam alaikum warahmatullah
wabarakatuh sekarang saya akan kembali
melaju mengajarkan tentang mata
pelajaran dasar-dasar konstruksi
bangunan nah hari ini yang akan saya
Terangkan adalah macam-macam gambar yang
dibutuhkan untuk konstruksi bangunan ya
Nah di dalam konstruksi bangunan itu
untuk dasarnya adalah beberapa gambar Ya
gambar itu adalah dibutuhkan untuk
sebagai patokan atau sebagai acuan dalam
pelaksanaan pembangunan konstruksi
bangunan tersebut ya Nah kalau kita
lihat ya kalau kita lihat yang paling
utama untuk yang namanya gambar ya
adalah yang pertama adalah denah dan
tampak Jadi kalau kalian lihat kalau
kalian lihat ya kalau kalian lihat
brosur Perumahan atau
Mbak yang paling utama adalah gambar
denah dan tampak nah ini contohnya di
ini nih gambar denah dan tampak nah ini
the Nah ya the nah kebetulan di sini
denah type 60 150 Apa maksudnya denah
tipe 60/160 Nah maksudnya adalah 60 ini
adalah luas dari bangunan tersebut 150
adalah luas dari tanahnya bagi contoh
kita lihat Nah di sini untuk luas bidang
tanahnya itu lebarnya adalah 10 m
kemudian panjang ke belakangnya adalah
15 m ya kamu lihat di sini panjangnya
adalah 15 m nah ini 15 m terlihat ya loh
Hai nih panjangnya 15 m Nah itu berarti
luas tanahnya secara keseluruhan adalah
150 nah kemudian 60 apa 60 itu adalah
luas dari bangunan yang ada di dalam
tanah tersebut ya biasanya lebih kecil
dari bangunannya lebih tahan dari kecil
dari tanahnya bangunannya karena
biasanya ada garasi ada taman kemudian
tidak dibangun semua beda halnya kalau
pada kenyataannya kalau di rumah di DKI
rumah itu kalau ada tanahnya 60 ya
bangunannya 60 jadi pintu itu persis
dipinggir jalan nah itu kurang bagus ya
Tapi karena kondisi mungkin tanah di
Jakarta mahal kondisi sekarang juga agak
sulit tanah yang ada di Jakarta sehingga
kebanyakan bangunan itu dipukulin ya
Tapi pada umumnya kalau kalian membeli
sebuah bangunan atau sebelah rumah
sebuah rumah dari sebuah developer atau
Kompleks ya biasanya bangun
tidak akan default nah 60 ini apa jumlah
dari luas bangunan ini misalnya Pak di
sini ada kamar tidur 2 setengah kali
tiga berarti berapa dikalikan ini dua
kali satu setengah ada seterusnya
dijumlahkan totalnya adalah kurang lebih
60 M2 nah ini semua satuannya adalah M2
Nah untuk denah ini biasanya digambar
dalam skala 1 banding 100 1 banding 100
pada umumnya nilai pada umumnya 1
banding 100 nah 1 banding 100 itu
maksudnya apa kalau disini adalah 10 m
ya di sini 10 m maka ini adalah di kita
Gambarkan menjadi sepuluh senti kalau
ini segalanya saat 1 banding 100 ya
begitu ini 15 m 15 m ini berarti ini 15
Nah kenapa di sini terus seribu di sini
tertulis seribu
200 nah sejarah harfiah kalian harus
dari tahu Kadang disini ditulisnya dalam
satuannya senti terkadang dalam
satuannya demeter eh satuannya m
keadaannya mm tapi yang pada umumnya
untuk standar arsitektur ini satuannya
adalah dalam milik dalam mm tapi tidak
tetapi banyak juga yang menggunakan
satuan ini menggunakan satuan centi nah
kalian harus Juli kalau ini 1000 jangan
ada lagi bertanya Pak ini 1000 ini
maksudnya seribu apa 1000cc Tika 1000 m
kah atau seribu milika nah yang dimaksud
seribu ini ya Cuma Seribu ini adalah
1000 cm ya kalau 1001-b arti kalau kita
jadikan M maka ini lebarnya adalah 10 m
begitu juga ini ini Rp1.500 berarti ini
adalah
Yua 15 m ya kadang ada yang pada umumnya
itu tadi saya bilang itu adalah standart
punya mm ditulisnya adalah Rp10.000
disini adalah Rp15.000 ya itu nah yang
dimaksud dengan gambar denah yang
dimaksud dengan gambar denah adalah
gambar bangunan dilihat dari atas dan
dipotong setinggi satu setengah meter
dipotong satu setengah meter contoh nih
ini ada bangunan tingginya 3 M maka kita
potong sini stretch gitu kan ditengah
ini kita petani crysearch kita potong
nah X tinggi satu setengah meter Nah
kalau kamu lihat ya kalau kamu lihat di
sini ada lambangnya itu kalau lambang
bata itu seperti ini ya Nih ada garis2
sini ya ada garis2 ini gambar dinding
bata maksudnya gambar dinding bata
dinding hebel pokoknya dinding ya ya
kemudian di pagar Ini pagar ini tidak
ada arsirannya tidak ada arsiran miring
eh garis dua ya Maksudnya apa Nah tadi
yang saya bilang adalah kalau yang
namanya bangunan itu atau gambar denah
itu adalah gambar bangunan dipotret
dilihat dari atas dan dipotong2 m Nah
kamu tahu tinggi dari pagar itu biasanya
berapa parity biasanya satu setengah
meter ya kalau tinggi satu setengah
meter maka dia yang terlihat hanya
adalah Sisinya saja Sisi paling luar dan
Sisi paling dalam tapi kalau untuk
dinding disini selain apa namanya Sisi
paling pinggir luarnya kanan kiri
Bataknya juga terlihat Nah itu maksudnya
seperti itu ya kemudian ada lagi yang
namanya gambar tampak nah tampak ini ada
tampak depan ada gambar
di samping Nah kenapa gambar tampak
depan ini posisinya di sini enggak di
sini ya kalau di dalam standar gambar
bangunan ia Ini namanya ada proyeksi ya
Jadi begitu ini gambarnya seperti ini
maka tampak depannya sebaiknya berada di
atasnya nah seperti ini ya proyeksi Nah
jadi kamu lihat ini kita tarik garis
lurus yang dinding pagar ini kita garis
lurus dinding ini ya dan seterusnya ini
kita garis tarik nah ini sejajar jadi
sejajar nah kebun ada lagi tampak
samping tampak samping adalah gambar
bangunan yang dilihat dari samping
absennya ada di gambar di samping
sebelah sini ya ini pak samping kiri kek
atau samping kanan kenapa harus ada
tampak samping kiri dan samping kanan
karena biasanya tampak samping kiri dan
tampak samping kanan itu berbeda Sama
dengan juga dengan tampak depan ada juga
tampak belakang ya itu ya Nah sekarang
cara menggambar denah dan gambar tampak
ya Ada juga yang namanya gambar potongan
ya gambar potongan nah ini contoh gambar
potongan gambar yang dimaksud gambar
potongan adalah gambar tampak yang
dipotong sesuai dengan garis potong
sesuai dengan garis potong ya untuk
melihat kondisi dalamnya contoh ini sini
ada tadi gambar denah tadi ya Nah ini
ada gambar denah seperti ini nah ini ada
a-teen adalah berfoto dipotong namanya
garis potong nah yang akan kita lihat
adalah dari sini ke atas ke atas ke atas
dan ke atas untuk Blade visi dalamnya
jadi ibaratnya kita belah set Kita bela
disini Saya mau menggambar bagian ininya
ya Nah ini yang terlihat makanya
terlihat bagian potongan ini sama
seperti tadi gabbarini nah ini kalau
atau disini berarti dan terlihat bagian
dalamnya ada pintu ini terbelah tapi
bagian sininya nih seperti tampak karena
memang tidak dipotong bagian sininya Ya
itu potongan-potongan itu ada potongan
melintang dan ada potongan membujur
maksudnya potongan melintang dan
potongan membujur itu seperti apa ya Nah
ini kita lihat lagi di gambar denah tadi
Nah kalau ini ya ini ada potongan
melintang kita mengaku membujur ini sini
jadi potongan garis x-men garis y jadi
potongan itu adalah untuk memperlihatkan
Sisi dalamnya dari bangunan tersebut
kalau tanpa kan kamu lihat di sini hanya
tampak depannya aja tapi kita gak bisa
lihat nih bagian dalamnya Seperti apa
pintunya di disini gimana guys di sini
ada jendela juga tidak terlihat di sini
ada pintu juga tidak terlihat Nah jadi
perlunya namanya gambar potongan nah
selain gambar potongan ada juga gambar
detail ya
dan contoh ini ini adalah gambar detail
pondasi nah gambar detail pondasi
seperti ini nah ini tadi yang saya
bilang potongan ini garis Batak nah ini
garis plasteran ya Nah ini Eh ini ada
tanah urug ini batu kali kemudian
sebenarnya harusnya ada anstamping ada
pasir urug Idih adalah fluff ya ini
sebelum diatas Pondasi yang mana ada di
soal UTS kemudian ada trasram trasram
itu adalah sama dengan pasangan dinding
bata hanya karena dia adanya di bawah
maka trasram itu aduk hanya dibuat kedap
air kalau dinding bata itu biasanya 1
banding 4 atau 1 banding 50 adukan Nya
maka untuk trasram itu 1 banding 2
Maksudnya apa 1 banding 2
Hai semen dua pasir Nah kalau 1 banding
Demak Yati satu semen Lima Pasir
otomatis yang lebih kedap air adalah
yang satu banding dua ya Nah adalah di
potongan untuk pondasi beton misalkan
ini gambarnya seperti ini gabruk pondasi
beton kalau kita lihat tadi yang di
gambar bangunan tingkat 2 lantai ini ya
kamu lihat nah ini pedasnya adalah
pondasi eh boleh ini pondasinya adalah
pondasi beton karena tinggi ya kamu
lihat di sini beton nah polisi betul
potongan Seperti apa ini tuh ya Jadi
kalau kita potong seperti ini ya ini ini
pondasi pondasi beton Nah di sini ada
detailnya detailnya itu detail sluf
naikkan seperti ini detailnya tingginya
sekian di sekian nah ini
nah dilihat dari atas nah ini juga ini
detail kolom detailed dan sebagai ini
gambar-gambar detail ya Nah gambar hotel
itu untuk memperlihatkan memperlihatkan
besinya menggunakan besi berapa dan
Banyaknya berapa ya itu salah satu
gambar-gambar yang apa namanya sebagai
acuan kamu untuk membangun sebuah rumah
nah satu lagi adalah gambar 3D nah
contohnya gambar 3D nah ini contoh di
gambar 3dnya seperti ini ya Nah kalau
kamu lihat kamu perhatikan ya kalau kamu
lihat ini adalah gambar bangunan 3D Ya
misalnya kamu lihat di sini bawah ini
adalah pondasi ya Eh kita lihat di sini
dipotong seperti ini pondasi di bawah
tanah ya kemudian di dinding ya ada di
dinding nah di dinding itu ada cat Acian
plesteran kemudian dinding bata ya gan
kemudian baru ada ring balok dan atap
ide contohnya Ini gambar 3D nah biasanya
Kadang orang awam itu kalau hanya
melihat gambar denah dan gambar dari
tampak kadang belum paham bener Oh
seperti apa sih bangunannya ya belum
seperti blue paham gambar bangunan itu
seperti apa ya makanya biasanya
dibuatkan lah gambar 3D Tiga dimensinya
ya gambar 3 dimensi nya itu sebagai
acuan owner awam untuk mempercantik
bangunan terlihat secara tiga dimensi ya
Nah hari ini kamu ulang-ulang materi ini
ya Ini adalah dasar Apa yang dimaksud
dengan gambar potongan Apa yang dimaksud
dengan gambar denah kemudian macam-macam
siapa namanya gambar detil Terus kenapa
apa namanya ini pondasi itu dibuat
dan apa ada Slug ada trasram kemudian
aduk hanya berapa dan sebagainya Ya saya
rasa materi hari ini tidak terlalu
banyak yah nanti saya akan upload
YouTube kamu tinggal lihat
berulang-ulang supaya kamu paham ya
karena kondisi saat ini kita masih belum
bisa secara luring secara tetap muka
tetapi mau nggak mau kita masih secara
daring ya serasa materi Hari ini saya
cukupkan dulu sampai disini silahkan
dipelajari dengan baik itu saja sok
Wassalamualaikum warahmatullah
wabarakatuh
hai hai
تصفح المزيد من مقاطع الفيديو ذات الصلة
How to Read Construction Drawings | Beginners Guide to Blueprint Reading | Architectural Drawings
Introduction Of Multi-storey Building (RCC-II,Lecture-1,Unit-1)#CivilEngineering #AdhyayanetuAcademy
HOW TO READ A COMMERCIAL SITE PLAN, UNDERSTANDING CONSTRUCTION DRAWINGS, PRINT READING LESSON #3
What Is Construction Planning?
How to read residential structural drawings
The Story of a Building, 1958 [Seagram Building in New York City]
5.0 / 5 (0 votes)
